G -S002-07 1004-004 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE M-7 list-1 M-7 Q’ty は、装置一台あたりのの員数を示しております。 The value in each “Q’ty” column shows the quantity per machine. 601 6301215549 BOL T 6 860M--1 10-3…
G -S002-07
0805-002
M-7 illust-1
ヘッド部
HEAD SECTION
Fig. M-7
基板認識カメラ
PEC Recognition Camera
612
601
603
604
602
611
See Fig. M-1
Key No.20
638
668
671
671
663
668
.
677
.
682
621
652
Special Specifidations
G -S002-07
G -S002-07
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
M-7 list-1
M-7
Q’ty
は、装置一台あたりのの員数を示しております。
The value in each “Q’ty” column shows the quantity per machine.
601 6301215549 BOLT 6 860M--110-301 221E00281
602 6300699340 ACCESSORY,P.C.B(BUSH) 6 860M--110-302 23L10044
603 6301215556 PLATE 2 860M--110-303 211D9046
604 6301358444 PLATE 2 860M--110-304 211DA501
611 6301267050 ASSY,SCOPE UNIT 2 -B36 860M--110-401 0Z100022
612 6301426198 LIGHTING UNIT 2 -E39 860M--110-402 4Z110181
621 6301597287 BRACKET 1
860M-A100040-A001
211FC819
638 6301308937 COVER 2 860M--110-138 211A9116
652 6301621661 ASSY,CORD 1 B03
860M-A100020-A052
0W201880
663 6300007527 BOLT,HEX-SCT 6 M3X10 860M--110-213 221A0007
668 6300007657 BOLT,HEX-SCT 8 M4X16 860M--110-218 221A0020
671 6301274546 SCR PAN+SW+W 3X6 8 860M--110-221 221E0594
677 4111412905 WASHER SPR 4 6 860M--110-227 221H0284
682 4111414008 WASHER V 4X9X0.8 6 860M--110-232 221H0315
HH-G300
G -S002-07
G -S002-07
0805-002
M-8 illust-1
ヘッド部
HEAD SECTION
Fig. M-8
ケーブル
Cable
Special Specifications
G -S002-07
-B36
-A31
-U25
-U03
-U147
-B3106
-B3108
-U37
-B3103
-E41
759
756
771
753
754
755
752
769
766
774
760
757
758
775
772
See Fig. M-3
Key No.246
See Fig. M-7
Key No.612
See Fig. M-7
Key No.611
See Fig. M-1
Key No.1
See Fig. M-6
Key No.519
See Fig. M-1
Key No.51
See Fig. M-5
Key No.423
See Fig. M-7
Key No.652
See Fig. M-2
Key No.133
X2502
X14701
25B1
25B5
25B4
25B2
X312A
X2506
X3108
X13701
X3701
X23601
X10306
X12507
X12501
X2504
X0306
X0305
B0308
X2511
X2512
X0308
X0309
X2503
X3601
X312BX312C
X2501
X31P1
E61
X2507
X311A
X256A
X256B
X316B
X316A
X2505
X3105
B3103
B3106
X256C
X316C
