2 Assembly Instructions - SIPLACE X-Series Head Reconfiguration Kits Head Reconfiguration Kits 07/2010 Edition 274

Head Reconfiguration Kits 2 Assembly Instructions - SIPLACE X-Series Head Reconfiguration Kits

07/2010 Edition

273

Fig. 2.15 - 9 90010131-020301ld3 circuit diagram (sheet 3)

For Machines Serial No. >= B326

For IC-Camera (Type 33) 55x45 dig (Item.No. 03016339) >= FS 04

respectively

FC-Camera (Type 25) 16x16 dig (Item.No. 03020578-) >= FS03

Additional CAN Cable to conect to

IC-Camera (03050239- ) CAN-Bus: IC-Camera

FC-Camera (03050550-) CAN-Bus: IC- und FC-Camera
