130- A コンベアステーション(メカ部品):NPM-D Conveyor Station (M echanical Parts):NPM-D パーツレイアウト Kit No. キット 品番 Kit Name キット名称 N610122572AA セクションNo. PARTS LAYOUT Section No. - - O425 ( KN610122572AA-07-1 )
Ref
No.
Remarks R
1
Q'ty
129-G
フレキシブルコンベアステーション(メカ部品):NPM-D
Flexible Conveyor Station (Mechanical Parts):NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610123280AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
COVER
2
1 N210146325AA
COVER
2
2 N210009673AA
COVER
2
3 N210009675AA
BRACKET
2
4 N210138440AB
BRACKET
2
5 N210138441AA
NUT-PLATE
2
6 KXFB03UPA00
NUT-PLATE
2
7 N210004525AA
NUT-PLATE
8
8 N210123047AA
BRACKET
1
9 N210141156AD
BRACKET
1
10 N210141157AE
BRACKET
2
11 N210146192AB
PLATE
2
12 N210146252AB
COVER
1
13 N610123296AA
COVER
1
14 N610123666AA
BRACKET
1
15 N610123669AA
COVER
2
16 N610123670AA
SCREW
7
17 KXF01BWAA00 C-1029-4X10
CAP
8
18 N510024547AA CP-328-B-5-G hole process
BOLT
8
19 N510017630AA
Hexagon socket Flat head bolt M5X12-10.9 A2J (Trivalent)
WASHER
7
20 N510049845AA C-1029-S-M4
HINGE
4
21 KXF0DXYXA00 BP-19-1-2-B
RUBBER-CUSHION
8
22 KXF01E0AA00 C-30-CS-2
BOLT
16
23 N510017517AA
SSS 003 Hexagon socket button head screw M4X12-10.9 A2J (Trivalent)
BOLT
8
24 N510001803AA SRBS-M4X12
PULL
2
25 KXF0DYFRA00 AP-291-3
SENSOR
1
26 N510042549AA
S
E3ZS-T81A-2
SCREW
4
27 N510018257AA
Cross recessed Truss head machine screw M4X10-4.8 A2J (Trivalent)
SW(800mm)
2
28 N610102219AA
S
O424
--
( KN610123280AA-11-7 )
130-A
コンベアステーション(メカ部品):NPM-D
Conveyor Station (Mechanical Parts):NPM-D
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
N610122572AA
セクションNo.
PARTS LAYOUT
Section No.
--
O425
( KN610122572AA-07-1 )
Ref
No.
Remarks R
1
Q'ty
130-A
コンベアステーション(メカ部品):NPM-D
Conveyor Station (Mechanical Parts):NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610122572AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
COVER
2
1 N210101303AC
COVER
2
2 N610122569AA
COVER
1
3 N610122570AB
COVER
1
4 N610122571AA
COVER
1
5 N610126657AA
GROMMET
2
6 N510031737AB C-30-SG-48A-EP-UL
BOLT
6
7 N510017534AA
SSS 003 Hexagon socket button head screw M4X6-10.9 A2J (Trivalent)
CAP
34
8 N510024547AA CP-328-B-5-G hole process
BOLT
34
9 N510017630AA
Hexagon socket Flat head bolt M5X12-10.9 A2J (Trivalent)
FRAME
4
10 N510057358AA SFF-364 L=532
FRAME
4
11 N510057355AA SFF-304 L=1350
FRAME
2
12 N510057356AA SFF-304 L=532
FRAME
8
13 N510057357AA SFF-304 L=376
FRAME
3
14 KXF0E10YA00 SFF-304 L=600
BRACKET
16
15 N510043582AA SFJ-N26
BRACKET
44
16 KXF0ATEAA00 SFJ-018
NUT
158
17 KXF0ATGAA00 SFB-002
NUT
22
18 KXF0ATHAA00 SFB-001
NUT
20
19 KXF0ATJAA00 SFB-006
NUT
4
20 N510013284AA SFN-LS6
NUT
20
21 N510013304AA SFN-LS5
CAP
200
22 KXF0ATFAA00 SFA-906
CABLE-SUPPORT
10
23 N510025949AA C1P-004C
BOLT
32
24 N510018820AA
Hexagon socket head cap screw M6X22-10.9 A2J (Trivalent)
BRACKET
1
25 N210144869AC
O426
--
( KN610122572AA-07-1 )
