Head Reconfiguration Kit 2 Assembly Instructions Head Reconfiguration Kit CPP fo r the SIPLACE X Ser ies Issue 03/2010 2.8 Removing the Placement Head 123 X Remove the two extensions for th e Y axis sto p [03075963-01] &…

2 Assembly Instructions Head Reconfiguration Kit CPP for the SIPLACE X Series Head Reconfiguration Kit

2.8 Removing the Placement Head Issue 03/2010

122

2.8.7 Removing the "Nozzle Station" Option

X For removing

the nozzle changer, refer to the Assembly Instructions for Nozzle Changer X-Series

[00196432-xx].

2.8.8 Removing the "Reject Bin Sensor" Option

2.8.9 Removing the "Stationary Camera" Option

2.8.10 Removing the "MTC" Option

If the CPP is operated with an MTC, the Y stop must be installed on the MTC side with an exten-

sion. 2

With a TwinHead, no extensions are necessary. 2

CAUTION: Danger of crashing

Always operate the placement heads with the appropriate nozzle changer for the rele-

vant head and the correct magazines. There is a danger of crashing when a false nozzle

changer is used.

When switching to a C&P20 head it suffices to change the magazines. 2

NOTE:

The nozzle changer of the CPP head can only be operated on machines with CAN

nodes. 2

NOTE:

When using the reject bin sensor option, an additional sensor for the large component

reject bin must be installed [03079030-xx]. 2

For details on the reject bin sensor option, refer to the Assembly Instructions "Reject Bin

Sensor SIPLACE / X-Series / D3 " [

00194716-xx]. 2

NOTE:

For details on the stationary camera, refer to the Assembly Instructions "Stationary Cam-

era SIPLACE X-Series" [

00194554-03]. 2

Head Reconfiguration Kit 2 Assembly Instructions Head Reconfiguration Kit CPP for the SIPLACE X Series

Issue 03/2010 2.8 Removing the Placement Head

123

X Remove the two extensions for the Y axis stop [03075963-01] "Adaption Stop Y Axis MTC").

NOTE:

For more details on MTC2, refer to the

Assembly Instructions "MTC2 on Component Trolley Docking Unit, X-S" [00194725-xx]

and the Installation Instructions "

MTC2 on SIPLACE HF" [00193897-xx]. 2

CAUTION:

An MTC cannot be used with an C&P20(A). 2

Standard Y axis stop (MTC with Twin-

Head)

Y stop for MTC with CPP

2 Assembly Instructions Head Reconfiguration Kit CPP for the SIPLACE X Series Head Reconfiguration Kit

2.9 Annex Issue 03/2010

124

2.9 Annex

2.9.1 Configuration Axis Unit A364

A1 A2

CE BE

0IN

ED ON

A3 A4

CE BE

0IN

ED ON

23 4

TBS 250/10X1

TBS 250 /20Y1

SDS 120/1.5Z2 (00353445-01)

DC/ DC Wandler Dp-Antriebe (03002397-)

Gantry

Axisunit A364 X-Serie CPP

15 V / 5A 15 V / 5A

5 V / 15A 15V/1,7A 15V/ 1,7A

LZS250/1000

Only in Axis unit PA2

DBM01/01NO2

Star

Gantry 3

SDS 120/2.5S1 (00353445-04)
