2 Assembly Instructions Head Reconfiguration Kit CPP for the SIPLACE X Series Head Reconfiguration Kit 2.5 Required Parts, Tools and Consumables Issue 03/2010 74 2.5.1 Part s List – CPP Head Reconfiguration Kit X Series …
Head Reconfiguration Kit 2 Assembly Instructions Head Reconfiguration Kit CPP for the SIPLACE X Series
Issue 03/2010 2.5 Required Parts, Tools and Consumables
73
2.5 Required Parts, Tools and Consumables
– Required Tools
Designation Item no.
Fixing screws for CPP - ISO 14580 - M4x18-8.8, nickel 03076575-xx
Torque wrench 03078400-xx
(old version: 00376504-xx)
Extension with joint (170xSK3) 03042635-xx
Extension, straight (170xSK3) 03043440-xx
Tool extension, straight TX20 03073256-xx
Bitholder for Screwdriver TorqueVario 03078706-xx
Screw locking varnish, gray 00318199-xx
Pressure tester with measurement cable 00313523-xx
Reconfiguration kit component trolley docking unit X 00378465-xx
Docking frame for the MTC (for TH / TH 2 gantry PA with MTC) 03009963-03
Mapping Testing plate HF/X/D3 508x450 00373952-xx
Calibration tool, version 3 03010565-xx
Calibration tool, version SST23 03034148-xx
Caliper 200 mm
(alternatively the caliper from the service engineer's standard
tool set)
03079617-xx
Universal head assembly stand 00363290-xx
Assembly Instructions Nozzle Changer CPP / C&P 20 A (from
SW 702) SIPLACE X-Series
00196432-xx
Assembly Instructions Reject Bin Sensor SIPLACE / X-Series
/ D3
00194716-xx
Assembly Instructions FlipChip Camera Digital 16 x 16 (SST
25) SIPLACE X-Series / D3 / D1
00194554-xx
Assembly Instructions Head Reconfiguration Kits X-Series 00194474-xx
Assembly Instructions MTC2 on Component Trolley Docking
Unit, X-S
00194725-xx
Assembly Instructions MTC2 on SIPLACE HF- / X-Series 00193897-xx
2 Assembly Instructions Head Reconfiguration Kit CPP for the SIPLACE X Series Head Reconfiguration Kit
2.5 Required Parts, Tools and Consumables Issue 03/2010
74
2.5.1 Parts List
– CPP Head Reconfiguration Kit X Series [00119764-xx]
– Placement Head CPP without camera [03053528-xx]
– According to customer request:
Camera C&P (type 29) 27x27 digital RK [03018637-xx] or
01005 camera for CPP-Kopf [00119783-xx]
– Parts set C&P20+DLM+TH to CPP X series [03074749-xx]
It consists of:
This is the parts set for replacing a C&P20, a DLM and a TwinHead with a CPP. It is the base
set for all further head reconfigurations.
It consists of:
NOTE:
The camera type is added during the configuration query of the Head Reconfiguration
Kit.
The C&P component camera (type 29) 27x27 digital RK [03018637-xx] is set as default.2
1 St Piping CPP / FHE X-series 03077156-xx
1 St Tube FHE / head valve CPP X-series 03077153-xx
1 St Tube FHE / holding circle CPP X-series 03077154-xx
2 St Plug QSC-4H 00330249-xx
1 St Plug QSC-8H 03010908-xx
1 St Plug QSC-12H 03015210-xx
1 St Cover, type D Di8,0 H15 plasticized PVC 03006728-xx
1 St Cooling tubes X motor 03006777-xx
1 St Cable set CPP / X-Serie 03074061-xx
1 St PCB / Headboard CPP 03077980-xx
1 St Amplifier SDS 120/1.5Z2 03070900-xx
1 St Nozzle station CPx cplt. / X-,B-series 03073328-xx
1 St Piping of nozzle station / with valve 03051467-xx
1 St Valve for nozzle station cplt. 03055785-xx
2 St DIN912-M2,5 x 16-A2-70 00350291-xx
1 St Y press-fit connection with push-on socket QSY-6H-4 03055792-xx
1 St Plug QSC-4H 00330249-xx
1 St PUN-CM 4x0.75 / 135 mm 03056097-xx
1 St PUN-CM 4x0.75 / 200 mm 03056096-xx
1 St Screw set camera/holding sheet 03082143-xx
1 St DIN 912-M2,5 x 12-A2-70 00304134-xx
1 St DIN 125-A 2.7-140HV-A2 00201583-xx
7 St DIN 913 - M 4 x 6-ST 00309422-xx
4 St DIN 6325 - 4m6 x 10-St 00331299-xx
Head Reconfiguration Kit 2 Assembly Instructions Head Reconfiguration Kit CPP for the SIPLACE X Series
Issue 03/2010 2.5 Required Parts, Tools and Consumables
75
– Add on set 1 / DLM+TH to CPP / x series [03082136-xx]
This package is only included if a DLM or a TwinHead is replaced with a CPP.
It consists of:
2
– Add on set 2 / TH to CPP / x-series [03082135-xx]
This package is only included if a TwinHead is replaced with a CPP.
It consists of:
2
– Retrofit kit MTC2 - CPP head [03077244-xx]
This package is only included if the CPP is to be operated with an MTC.
It consists of:
1 St FHE Retrofitting set X-Series 03073841-xx
2 St DIN 7991-M3 x 8-8.8 00357791-xx
1 St Holder Plate Weldment 03074226-xx
1 St Nozzle station CPP cplt. / X4i 03074861-xx
3 St Shim plate for nozzle reject device 03039514-xx
2 St DIN 7991-M4 x 20-8.8 00333782-xx
1 St Rework air connection X-motor plate 03077155-xx
1 St Air connexion 03076774-xx
1 St mounting, type Panduit TA. 00342838-xx
1 St DIN 912-M3 x 20-A2-70 00201469-xx
1 St DIN 125-A 3.2-140HV-A2 00316904-xx
1 St DIN912-M3 x 8-A2-70 00303193-xx
2 St Cable strap B=2,5 mm L=102 mm Panduit 00308458-xx
1 St Screw set valve nounting 03082144-xx
1 St DIN 912-M3 x 16-A2-70 00325349-xx
1 St DIN 912-M2,5 x 16-A2-70 00350291-xx
1 St Plug-in Board /DC-DC Converter DP 03002397-xx
1 St Component reject box up to 6x6 03049954-xx
1 St Component reject bin up to 6x6 03039042-xx
1 St Sensor mounting LLK 03077835-xx
1 St Sensor mounting LLK 03009986-xx
2 St DIN 7981 - ST3.5 x 6,5-C-H-A2 03046777-xx
2 St DIN912-M3 x 6 PA 03077852-xx
1St
Servo amplifier SDS120/2,5S1
00353445-xx
1St
Box
03048638-xx
2St
DIN 913 - M 6 x 50-ST
03005958-xx
1St
Notch socket
03010773-xx
1St
Adaption stop Y-axis MTC
03075963-xx
