Operating Instructions Model No. KXF-4R4C KXF-4Q4C KXF-D24C Thank you for purchasing CM201/CM202, the modular high speed placement ma- chine. Before placing the machine in service, be sure to read the instruction manual …
Operating Instructions
Model No.
KXF-4R4C
KXF-4Q4C
KXF-D24C
Thank you for purchasing CM201/CM202, the
modular high speed placement ma-
chine.
Before placing the machine in service, be sure to read the instruction manual for
proper usage.
After that, store it carefully and it if necessary.
4Q4C-E-IMAB-0004
Modular High Speed Placement Machine
CM201/CM202
Installation Manual
1
“Use of this machine:
This machine is designed and constructed to be used for placing
electric and electronic components on PCB.
This machine shall be used for this purpose only.
It shall not be used for any other purpose.”
“Operation of this machine:
This machine shall be operated by professional, specially trained operators.
It shall not be operated by non-professional, not specially trained operators.
For the training coursed you, make contact with Panasonic Factory Solutions Co., Ltd., PFAE or PIEL.”
Machine was manufactured by: Panasonic Factory Solutions Co., Ltd.
441-13, Nagahasu, Tateishi-machi, Tosu-city, Saga, Japan
TEL:81-942-84-2644
FAX:81-942-84-2636
For Service and Supply of Spares in Europe
you may contact Panasonic Europe:
Continental Europe
PFAE
Panasonic Factory Automation Europe
Winsbergring 15
22525 Hamburg Germany
Phone number :0049-(0)40-85386-321
Fax number : 0049-(0)40-85386-332
United Kingdom
PIEL
Panasonic Industrial Europe (U.K.)
Panasonic House, Willoughby Road
Bracknell, Berks. RG12 8 FP
Phone number : 0044-(0)1344-853267
Fax number : 0044-(0)1344-425970
Year: 2004
4Q4C-E-IMA00-B01-01
M11E
DO NOT ALLOW ANY PERSON WHO HAS NOT RECEIVED SPECIAL TRAINING
TO OPERATE THE MACHINE.
The machine may be operated improperly and injure you.
Either carry out training by yourself, or consult the manufacturer.
WARNING
