ORGANIZATION OF MANUALS
5 manuals are attached to this machine. They are classified info 4 types. Use each
manual according to the working purpose and person in charge.
The production data of the line including this machine are programmed on PT. Refer to the instruction
manuals accompanied with PT.
Manuals of this machine
This manual is for the operators and engineers of the machine. It
describes the operating procedure, precautions and information which
is necessary for safe and effective operation.
Operating Manual
This
manual
This manual is for the persons who maintain the machine. It describes
simple inspection/adjustment and replacement of consumable parts.
Troubleshooting is also described.
Maintenance Manual (1/2, 2/2)
The assembly of each unit is individually indicated by the exploded
views of parts. Use this list when ordering parts or confirming the
assembly of parts.
Parts List
Installation Manual (Accompanies CM201-DU/202-DU/202-DHU only.)
This manual is for the installation of this machine.
