KLC-1304 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…
KLC-1304
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KLC-M2223-00 DAMPER
1 /
Í
39
KLC-M2238-00 BRACKET,STOPPER
1 /
Í
2
KLC-M2225-00
BRACKET,DOG
2
/
Í
40
KLC-M2239-00 TAPE,XT AXIS 1
1
/
Í
3
KLC-M2226-00 BRACKET COVER
1 /
Í
41
KLC-M223A-00 TAPE,XT AXIS 2
1 /
Í
4
KLC-M2227-00 BRACKET,SENSOR
1 /
Í
42
KLC-M225A-00 PLATE,HNS.
1 /
Í
5
KLC-M2228-00 COVER,HNS
1 /
Í
43
91312-06008 BOLT HEX.SOCKET HEAD
2
6
KLC-M2231-00 BRACKET1,DUCT
1 /
Í
44
7
KLC-M2232-01 DUCT2,HNS
1
/
Í
45
8
KLC-M2233-01 BRACKET1,HNS
2 /
Í
46
9
KLC-M2234-01 BRACKET2,HNS
2 /
Í
47
10
KLC-M224A-00 HOLDER SET,XT AXIS
1 /
Í
48
11
KLC-M2266-00 HOLDER,NUT X AXIS
1 /
Í
49
12
KLC-M2271-A0 XT AXIS B.S ASSY
1 /
Í
50
13
KLC-M2282-00 DOG.ORIGIN
1 /
Í
51
14
KLC-M2283-00 DOG,2ND LIMIT
2 /
Í
52
15
KLC-M22C1-00 COVER1,BS
1 /
53
16
KGT-M2220-00 COUPLING,X-AXIS
1 /
Í
54
17
KHN-M224K-00 COLLAR B
2 /
55
18
KHN-M224J-00 COLLAR A
2
/
56
19
KHN-M22AD-00 GREASE NIPPLE
1
/
Í
57
20
KHN-M22F6-00 WASHER,SWR06
4 /
Í
58
21
KHY-M224H-00
DAMPER
1 /
59
22
90KA1-201462 AC SERVO MOTOR
1 B
Í
60
23
90990-01J039 BOLT, HEX. SOCKET HEAD
4 61
24
90990-41J138 COLLAR
1 62
25
91312-03006 BOLT HEX.SOCKET HEAD
4
M3X6
63
26
91312-04010 BOLT HEX.SOCKET HEAD
4
M4X10
64
27
91312-05012 BOLT HEX.SOCKET HEAD
12
M5X12
65
28
91312-06020 BOLT HEX.SOCKET HEAD
8
M6X20
66
29
91312-06030 BOLT HEX.SOCKET HEAD
4
M6X30
67
30
91312-06045 BOLT HEX.SOCKET HEAD
4
M6X45
68
31
92012-04012 BOLT,BUTTON HEAD
1
M4X12
69
32
92012-04025 BOLT,BUTTON HEAD
2
M4X25
70
33
92902-04200 WASHER PLAIN
8 71
34
97602-04306 SCREW,BIN.HEAD W/W.
6 72
35
98902-04005 SCREW BINDING HEAD
10 73
36
98702-06014 SCREW, FLAT HEAD
8 74
37
KLC-M652C-01 SENSOR XT ORG ASSY
1 B
Í
75
38
KLC-M652D-01 SENSOR XT OT ASSY
1 B
Í
76
3
1
XT-Motor / Sensor
Moving-axis
