KLC-1304 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…
KLC-1304
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KLC-M910K-00 DAMPER 1
2
/
Í
39
2
KLC-M910L-00 SPACER
2
/
Í
40
3
KLC-M9111-00 HOLDER,BRG.
1
/
Í
41
4
KLC-M9113-00 HOLDER2,MOTOR
1
/
Í
42
5
KLC-M9114-00 PLATE,BRG.
1
/
Í
43
6
KLC-M9115-00 COUPLING
1
/
Í
44
7
KLC-M9116-00 PLATE1,BRG.
1
/
Í
45
8
KLC-M9117-00 SPLINE 1
1
/
Í
46
9
KLC-M9118-00 SPLINE 2
1
/
Í
47
10
KLC-M9119-00
HOLDER6,BRG.
1
/
Í
48
11
KLC-M911A-00 PLATE,BASE
1
/
Í
49
12
KLC-M911B-00 PLATE,BASE
1
/
Í
50
13
KLC-M911D-00 BELT 186-3GT-9
1
A
Í
51
14
KH2-M9121-00 BEARING
2
/
Í
52
15
KGK-M9170-00 DC MOTOR ASSY.
1
B
Í
53
16
KG2-M9108-11 COLLAR,CONVEYOR
2
/
Í
54
17
KLC-M911F-00 PULLEY 1,SPLINE
2
/
Í
55
18
KGT-M9193-00 NUT PLATE
4
/
Í
56
19
KH2-M9105-11 PULLEY,MOTOR:P30-3GT
2
/
Í
57
20
90933-01J804 BEARING
1
/
Í
58
21
90990-41J006
COLLAR
1
/
Í
59
22
90990-41J022 COLLAR
1
/
Í
60
23
KLC-M914F-00 BELT
2
E
61
24
91312-04006 BOLT HEX.SOCKET HEAD
4
M4X6
62
25
91312-04010 BOLT HEX.SOCKET HEAD
6
M4X10
63
26
91312-04014 BOLT HEX.SOCKET HEAD
2
M4X14
64
27
91312-04050 BOLT HEX.SOCKET HEAD
4
M4X50
65
28
91312-05008 BOLT HEX.SOCKET HEAD
2
M5X8
66
29
91312-05014 BOLT HEX.SOCKET HEAD
11
M5X14
67
30
91312-05025 BOLT HEX.SOCKET HEAD
2
M5X25
68
31
92902-04600 WASHER PLAIN
2 69
32
92902-05600 WASHER PLAIN
4 70
33
92012-03010 BOLT,BUTTON HEAD
8 71
34
90152-04J04 SCREW, SET
4 72
35 73
36 74
37 75
38 76
6
3
Transport
Conveyor
