KLC-1304 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…
KLC-1304
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KLC-M91K0-00 CONV. SENSOR ASSY 1 /
Í
39
2
KLC-M912M-00 PLATE,SENSOR
4
/
Í
40
3
KLC-M9165-00 BRACKET,SENSOR 2 /
Í
41
4
KLC-M915T-00 PALTE1,SENSOR 1 /
Í
42
5
KLC-M915J-00 HOLDER,SENSOR 1 /
Í
43
6
KLC-M9191-00 SENSOR HEAD 1 2 B
Í
44
7
KLC-M9192-00 SENSOR HEAD 2 4 B
Í
45
8
KLC-M9193-00 SENSOR HEAD 3 1 B
Í
46
9
KLC-M9194-00 SENSOR HEAD 4 1 B
Í
47
10
KLC-M652P-00 SENSOR PCB CHK1 ASSY 1 B
Í
48
11
KLC-M652P-11 SENSOR PCB CHK2 ASSY 1 B
Í
49
12
KLC-M652P-21 SENSOR PCB CHK3 ASSY 1 B
Í
50
13
KLC-M653J-00 SENS.CLAMP DWN1 ASSY 1 B
Í
51
14
KLC-M653J-11 SENS.CLAMP DWN2 ASSY 1 B
Í
52
15
KLC-M919A-00 FABER ADAPTER 3 /
Í
53
16
KLC-M9195-00 TUBE 1 /
Í
54
17
KLC-M9196-10 TUBE 1 /
Í
55
18
KLC-M9196-20 TUBE 1 /
Í
56
19
KLC-M9196-30 TUBE 1 /
Í
57
20
KLC-M9196-40 TUBE 1 /
Í
58
21
KLC-M9196-50
TUBE 1 /
Í
59
22
KLC-M9197-10 TUBE 1 /
Í
60
23
KLC-M9197-20 TUBE 1 /
Í
61
24
KLC-M9198-10 TUBE 2 /
Í
62
25
KLC-M9198-20 TUBE 2 /
Í
63
26
91312-03008 BOLT,HEX.SOCKET HEAD 12 M3X8
64
27
90990-11J001 SCREW,PAN HEAD W/W 9
65
28
92902-03600 WASHER PLAIN 4
66
29
98902-03006 SCREW BINDING HEAD 2
67
30
98902-03012 SCREW BINDING HEAD 2
68
31
98502-03004 SCREW PAN HEAD 8
69
32
92A08-02303 SET SCREW M2x3 2
70
33
KLC-M915K-00 HOLDER,SENSOR 1 /
Í
71
34 72
35 73
36 74
37 75
38 76
6
10
Conv.-Sensor Assy
Conveyor
