KGS_YG100_PL - 第9页
3 3 Feeder Floating Detection 24 (Fiber T ype) Feeder Holder KGS-101 1 1 17 2 4 15 18 9 10 12 13 14 14 1 1 5 8 7 12 STD FES 6 16 14 12 19 19 19 13 10 2 4 1 15 9 5 8 14 1 1 3 3 19 No. Part No. Part Name Q'ty Remarks …
2
3
Feeder Holder 24(CLI/IND)
Feeder Holder
KGS-1109
IND TYPE
6
44,45
7
5
34
17
36
24
16
37
37
37
17
14
15
37
28
33
28
32
8
30
31
31
11
12
43
4
9>8
2
3
13
33
32
28
18
1
42
31
27
10
30
31
33
33
32
18
28
29
29
20
40
34
26
21
22
25
23
35
35
35
19
39
38
41
32
16
OLD
5
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGS-M3C01-M0X PLATE M, FEEDER 1
2 $BF4BU JOINT 24
3 KG2-M3407-A0X AIR JOINT 24
4 KGS-M3402-M0X GUIDE M-1, TAPE 1
5
KGS-M3403-M0X GUIDE M-2,TAPE 1
5-1
KGS-M3403-M1X GUIDE M-2,TAPE 1 (2005/10/24) MB00059 NG
6 KGS-M3E03-00X GUIDE E-2, TAPE 1
7 KGS-M3E04-00X GUIDE E-3, TAPE 1
8 KGA-M3C05-01X STAND, 1 1
8-1 KGA-M3C05-S0X STAND, 1/2 SET 1
8 and 9 Set parts (2010/4/5) MG30148
9 KGA-M3C06-01X STAND, 2 1
9-1
Delete (2010/4/5) MG30148
10 KGS-M3408-M0X BRACKET M VALVE 1
11 KGS-M3409-M0X COVER M VALVE 1
12
KGS-M3410-80X
VALVE ASSY, 24-R 1 R TYPE
KGS-M3410-70X VALVE ASSY, 24-L 1 L TYPE
13 KM0-M3417-00X GUIDE, 4 1
14 KGS-M3E01-00X LIGHT GUIDE 3
15
16 KGS-M3E10-00X GUIDE TAPE BRACKET, R 1
17 KGS-M3E11-00X GUIDE TAPE BRACKET, L 1
18
KGS-M3430-01X LABEL,FEEDER 24 1 1-24/25-48
KGS-M3430-11X LABEL,FEEDER 24 1 2-23/26-48
KGS-M3430-20X LABEL,FEEDER 24 1 101-124/125-148
KGS-M3430-30X LABEL,FEEDER 24 1 101-123/126-147
19 KGR-M4452-12X ID READER BOARD ASSY 3
20 KGA-M3C20-10X PLATE 3
21 KGA-M3C21-00X BOX R 1
22 KGA-M3C22-00X COVER R 1
23
KGR-M4476-05X READER CTRL BD. ASSY 1
23-1 KGR-M4476-06X READER CTRL BD. ASSY 1 (2006/2/6) MC20026 OK
24 KGS-M4576-01X FDR LED BOARD ASSY 3
25 KGA-M3C23-00X WINDOW 1
26 KGA-M3C24-00X SEAL, CAUTION 3
27 91317-03006 BOLT HEX. SOCKET HEAD 4
28 91317-04010 BOLT HEX. SOCKET HEAD 4
29 91317-06020 BOLT HEX. SOCKET HEAD 4
30 91317-08020 BOLT HEX. SOCKET HEAD 4
31 90990-12J005 SCREW BINDING HEAD 10
32 92907-04200 WASHER PLAIN 8
33 92990-04400 WASHER EXTL. TOOTHED 8
33-1 90172-00J040 WASHER EXTL. TOOTHED 8
(2008/4/14) ME40115 OK
34 98707-03008 SCREW, FLAT HEAD (+) 12
35 98907-03006 SCREW BINDING HEAD 11
36 98907-03008 SCREW BINDING HEAD 6
37 98907-04006 SCREW BINDING HEAD 2
38 90562-03J100 SPACER 4
39 99480-03008 PIN, PARALLEL 6
40 KGR-M66T7-10X HNS, ANT CTRL 3
41 KGR-M66V9-11X HNS, FDR. CUNET 1
42 $UY8 JOINT 1
43
KGA-M37P0-00X VALVE KIT 1
SPARE
44 KGS-M66W0-00X HNS , INDI , BANK1,4 1 LEFT TYPE
45 KGS-M66W1-00X HNS , INDI , BANK2,3 1 RIGHT TYPE
3
3
Feeder Floating Detection 24 (Fiber Type)
Feeder Holder
KGS-1011
1
17
2
4
15
18
9
10
12
13
14
14
11
5
8
7
12
STD
FES
6
16
14
12
19
19
19
13
10
2
4
1
15
9
5
8
14
11
3
3
19
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGS-M3455-10X SENSOR ASSY (L=300) 1 AMP & FIBER
2 KV7-M3901-00X BRACKET SENSOR 2 1 FRONT TYPE
3 KGS-M3901-00X BRACKET SENSOR 2 1 REAR TYPE
4 KG7-M3906-00X BRACKET 6 1
5 KV7-M3910-01X BRACKET SENSOR, 1 1
6 KGA-M3941-02X BRACKET 4-1, SENSOR R 1 FR RL TYPE
7 KGA-M3942-02X BRACKET 4-2, SENSOR R 1 FL RR TYPE
8 KGA-M3951-00X BLOCK, SENSOR 1
9 KGA-M3952-00X BRACKET, AMP. 1
10 91317-03012 BOLT HEX. SOCKET HEAD 2
11 91317-03020 BOLT HEX. SOCKET HEAD 2
12 91317-04012 BOLT HEX. SOCKET HEAD 6
13 92907-04200 WASHER PLAIN 4
14 92A08-03304 SET SCREW 2
15 98907-03006 SCREW BINDING HEAD 2
16 92A08-05310 SCREW, SET 3
17 KGA-M3943-00X BRACKET 4-3, SENSOR R 1
18 90115-02J010 BOLT HEX. SOCKET HEAD 2
19 KGA-M3456-00X FIBER, SENSOR 1 FIBER Only
4
3
Feeder Floating Detection 24 (STD)
Feeder Holder
KGS-1109
Front
Back
RightLeft
RightLeft
2
1
1
15
9
11
4
14
5
15
16
18
14
12
17
12
17
13
11
10
15
15
1
14
3
3
3
3
2
1
4
5
16
15
18
14
12
17
13
2
1
1
15
9
11
4
14
8
15
16
18
14
13
11
10
1
14
2
1
4
7
16
15
18
14
12
17
13
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGS-M3961-00X SENSOR, LASER ASSY 1
2 KGS-M3951-00X PLATE SENSOR 1
3 KGS-M3910-00X BRACKET SENSOR, 1 1
4 KGS-M3906-00X BRACKET 6 1
5 KGS-M3901-C0X BRACKET SENSOR, 2 1
6
7 KGS-M3901-P0X BRACKET SENSOR, 2 1
8 KGS-M3901-N0X BRACKET SENSOR, 2 1
9 KGS-M3941-00X BRACET 4-1 SENSOR 1
10 KGS-M3942-00X BRACET 4-2 SENSOR 1
11 KG2-M3903-10X SEAL, LASER 1
12 91317-03012 BOLT HEX. SOCKET HEAD 2
13 90115-02J005 BOLT HEX. SOCKET HEAD 2
14 91317-04010 BOLT HEX. SOCKET HEAD 4
15 91317-04012 BOLT HEX. SOCKET HEAD 6
16 92907-04200 WASHER PLAIN 4
17 92907-03200 WASHER PLAIN 2
18 KGS-M3911-00X SQUARE WASHER 4 (2005/12/12) MBY0069
