- - 79.I FS - N X COM P O NENTS(1 ) 4 5 1 5 7 4 3 4 2 4 3 5 6 4 4 4 1 5 5 4 6 4 7 5 4 2 9 2 9 2 1 1 1 4 1 3 1 2 2 8 3 2 A 3 0 B 3 4 3 3 3 1 2 9 8 9 7 6 B 5 2 7 4 2 0 2 3 2 6 2 4 2 4 1 0 1 5 1 6 1 8 8 9 7 2 5 4 0 3 7 1 …
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-26506 DISCHARGE_GUIDE_ASM_REV_B 1
2 401-38858 DISCHARGE_GUIDE_UPPER_REV_B (1)
3 401-25970 TAPE_GUIDE_C_ASM_REV_B (1)
4 401-38839 TAPE_GUIDE_C (1)
5 SL-6030692-TN SCREW M3 L=6 (7)
6 401-38813 SHAFT (1)
7 401-17450 ONEWAY CLUTCH (1)
8 401-17433 HUSING (1)
9 401-17434 ARM (1)
10 401-17436 CYL JOINT (1)
11 E1038-871-000 PLATEN LOCK CAM SCREW (1)
12 401-38820 CYL_SUP_10 (1)
13 SL-6030692-TN SCREW M3 L=6 (2)
14 401-17440 CYLINDER (1)
15 PC-0105190-00 SPEED CONTROLLER (2)
16 NM-6040001-SC NUT M4X0.7 TYPE1 (1)
17 PJ-3010400-04 REDUCER (2)
18 401-38816 TAPE_GUIDE_D (1)
19 BT-0400251-EA URETHANE TUBE BLUE 4X2.5 (0.4)
20 401-17435 BRG PLATE (4)
21 SB-1080007-00 BEARING (4)
22 SL-6030692-TN SCREW M3 L=6 (8)
23 401-38811 SP_HOOK_BR (1)
24 SL-6040892-TN SCREW M4 L=8 (4)
25 401-26507 BELT_PLATE_ASM_REV_B (9)
26 401-38817 PLATE_A (1)
27 401-38818 PLATE_B (1)
28 401-38812 IDLER (1)
29 401-17446 IDLER (1)
30 401-17447 IDLER SHAFT (1)
31 401-17448 COLLAR A (1)
32 401-38819 BELT (1)
33 SB-1040005-00 BEARING (1)
34 SM-1020301-SN SCREW (1)
3
5 SM-8030302-TP SCREW M3X3 (2)
36 401-25967 SPACER (1)
37 SL-6031092-TN SCREW (1)
38 WP-0320500-SC WASHER M3 (1)
39 NM-6030002-SC NUT M3X0.5 TYPE2 (1)
40 SL-6030692-TN SCREW M3 L=6 (4)
41 WP-0841601-SC WASHER M8 (9)
42 RE-0600000-K0 E-RING 6 (13)
43 400-94891 SPRING 0.69N (9)
44 401-38810 GUIDE_SUP (2)
45 SL-6040892-TN BOLT (8)
46 SM-3040652-TN SCREW M4 L=6 (4)
47 401-46779 FILL_GAP_PLATE (1)
48 SL-4040891-SC SCREW M4X8 (4)
49 401-38803 GUIDE_INNER (1)
50 SL-6030692-TN SCREW M3 L=6 (5)
51 401-38806 TAPE_GUIDE_BOTTOM_A (1)
52 400-94843 HINGE B-1146-3 (2)
53 NM-3040510-SL FLANGE NUT (4)
54 401-26044 DISCHARGE_GUIDE_LOWER_REV_B (1)
55 SL-6040892-TN BOLT (2)
56 SL-6040892-TN SCREW M4 L=8 (4)
57 SL-6030692-TN SCREW M3 L=6 (2)
58 401-38849 DISCHARGE_COVER (1)
59 SL-6040892-TN SCREW M4 L=8 (4)
60 400-92716 TAPE CUTTER DANGER LABEL (1)
61 168-70206 GRAVITY SEAL (1)
62 401-14008 DISCHARGE GUIDE 3 (1)
63 401-26516 CUTTER_CABLE_BR_ASM (1)
64 PV-0100060-00 HAND VALVE (1)
65 SL-6042592-TN SCREW (2)
66 HX-0002400-0D CLAMP (2)
67 401-38821 CUTTER_CABLE_BR (1)
- -
79.IFS-NX COMPONENTS(1)
4 5
1
5 7
4 3
4 2
4 3
5 6
4 4
4 1
5 5
4 6
4 7 5 4
2 9
2 9
2
1 1
1 4
1 3
1 2
2 8
3 2
A
3 0
B
3 4
3 3
3 1
2 9
8
9
7
6
B
5
2 7
4
2 0 2 3
2 6
2 4
2 4
1 0
1 5
1 6
1 8
8
9
7
2 5
4 0
3
7 1
3 7
3 8
A
3 9
3 5
3 5
2 7
7 4
7 7
7 5
7 6
7 3
6 2
6 4
6 5
6 6
6 3
7 2
6 8
6 7
5 8
5 9
6 1
6 0
3 6
1 9
1 7
7 0
6 9
7 8
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-69218 E_BANK_ASSY(CAN) 1
2 401-10281 E BANK SUB ASSY (1)
3 401-28160 E_BANK_BASE (1)
4 E2602-721-000 BANK LOCATE BUSH A (2)
5 E2609-721-000 BANK LOCATE PIN A (1)
6 E2610-721-000 BANK LOCATE PIN B (1)
7 NM-6080003-SC NUT M8 (2)
8 WS-0820002-KN SPRING WASHER M8 (2)
9 WP-0841601-SC WASHER 8.4X17.4X1.6 (2)
10 401-28166 MARK STAND (1)
11 E2505-729-0A0 MARK ASM. (1)
12 E2505-729-000 MARK BASE (1)
13 E2601-725-000 MARK (1)
14 SL-6041292-TN SCREW (2)
15 SL-6052092-TN SCREW (2)
16 401-03746 FIXING PLATE (4)
17 SM-3041052-TN SCREW M4 L=10 (12)
18 401-03747 FIXING BLOCK (4)
19 SM-6041402-TN SCREW M4X0.7 L=14 (12)
20 400-84713 E BANK SHIM 0.02 (8)
21 400-84714 E BANK SHIM 0.03 (8)
22 400-84715 E BANK SHIM 0.05 (8)
23 400-84699 E BANK SHIM 0.10 (12)
24 SM-8040612-TP SCREW M4 L=6 (8)
25 SM-8030602-TP SCREW M3X0.5 L=6 (8)
26 SM-8041852-TP SCREW M4 L=18 (8)
27 SM-6040802-TN SCREW M4X0.7 L=8 (16)
28 E3074-729-000 BEARING SHIM D (2)
29 401-03748 RAIL GUIDE 9 (3)
30 401-03749 RAIL GUIDE 10 (1)
31 SM-6040802-TN SCREW (16)
32 400-85590 GUIDE_PLATE (41)
33 SM-3030552-TN SCREW M3 L=5 (82)
34 SM-1030552-TN PLATE SCREW M3 L=5 (41)
35 401-28162 LOCK SHAFT (2)
36 WP-0430801-SC WASHER M4 (8)
37 SL-4030881-SC SCREW M3 L=8 (8)
38 401-38827 E_BANK_BASE_COVER (1)
39 SM-0040601-SC SCREW M4X0.7 L=6 (8)
40 EA-9500B02-00 CABLE BAND 150 (10)
41 400-93577 FDC BRACKET ASSY (1)
42 400-93591 FDC BRACKET STAY R (1)
43 SL-6061292-TN SCREW (4)
44 401-28140 FDC BRACKET (1)
45 SL-6051092-TN BOLT (4)
46 400-93594 ETF POSITION LABEL(40) (1)
47 400-92647 EF IF CBL 1-5 ASM (1)
48 400-92648 EF IF CBL 6-10 ASM (1)
49 400-92649 EF IF CBL 11-15 ASM (1)
50 400-92650 EF IF CBL 16-20 ASM (1)
51 400-92651 EF IF CBL 21-25 ASM (1)
52 400-92652 EF IF CBL 26-30 ASM (1)
53 400-92653 EF IF CBL 31-35 ASM (1)
54 400-92654 EF IF CBL 36-40 ASM (1)
55 HK-0791900-00 CONNECTOR (80)
56 400-93590 FDC BRACKET STAY L (1)
57 HX-0022300-0A BUSHING (0.14)
58 401-69186 BANK_PCB_BOX_ASSY_IS (1)
59 HX-0035400-0E BOARD PARTS (4)
60 SL-4030691-SC SCREW M3 L=6 (6)
61 401-69160 E_BANK_PCB_BASE_IS (1)
62 HX-0067100-00 GROMMET (0.21)
63 400-71185 ELEC BANK 10 PCB ASM (1)
64 HX-0067100-0A GROMMET (0.25)
65 HX-0029400-00 FIXED BASE (8)
66 SL-4030691-SC SCREW M3 L=6 (8)
67 401-69161 BANK_PCB_COVER_IS (1)
68 SL-6030892-TN SCREW (4)
69 401-69045 BANK ID PCB ASM (1)
70 SL-4030691-SC SCREW M3 L=6 (3)
71 HX-0029400-00 FIXED BASE (8)
72 SL-6051092-TN BOLT (4)
73 401-07154 CLOSE LABEL (1)
74 E2732-721-000 BANK GUIDE ROLLER 4
75 400-93582 FINGER GUARD BR 1
76 SL-6040892-TN BOLT 4
77 400-01734 SCREW 4
78 CM-6005001-03 CHINA ROHS LABEL 10 L 1
