KE-3010A_KE-3020VA_KE-3020VRA-Rev06 - 第81页
- - REF.NO NOTE PART NO D E S C R I P T I O N Qty 1 WP-105200 1-SC WAS HER 10 4 2 40 1-46967 CONVEYOR_VALVE_UNIT 1 3 401 -46964 MANIFOLD_VALVE_AS M (1) 4 PV-91 50050-00 SOLENOID VALVE INS TALLING B ASE (1) 5 #01 PV-150…
- -
37.PWB CONVEYOR COMPONENTS(10)
1 3 1 4
2 0
1 9
1 8
1 7
1 5 1 6
2 6
1
2 5
2 5
1
1 2
2 9
2 8
2 7
1 1
2
1 0
2 2
2 1
2 4
2 3
4
8
9
7
9
9
6
5
3
3 0
3 3
3 2
3 6
3 5
3 4
3 1
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 WP-1052001-SC WASHER 10 4
2 401-46967 CONVEYOR_VALVE_UNIT 1
3 401-46964 MANIFOLD_VALVE_ASM (1)
4 PV-9150050-00 SOLENOID VALVE INSTALLING BASE (1)
5
#01
PV-1502093-00 5 PORT ELECTROMAGNETIC VALVE (2)
6 PX-0500030-00 SILENCER (1)
7 SM-3040652-TN SCREW M4 L=6 (2)
8 PX-5000140-00 PLUG (2)
9 HX-0070600-0A MOUNT BASE (3)
10 401-47000 CONVEYOR_VALVE_STAGE (1)
11 SL-6041092-TN SCREW M4 L=10 (2)
12 SL-6051092-TN BOLT 2
13
#02
401-46981 WAIT_SENSOR_UNIT_ML 1
14
#02
401-46982 WAIT_SENSOR_UNIT_MR 1
15
#02
401-47011 WAIT_SENSOR_BR_ML (1)
16
#02
401-47012 WAIT_SENSOR_BR_MR (1)
17 E2169-721-000 HOLD PLATE (1)
18 SL-6041292-TN SCREW M4 L=12 (2)
19 401-35828 LR WAIT COUT SENS ASM (1)
20 SL-4031091-SC SCREW M3 L=10 (2)
21 400-93920 HANDLE SHAFT 1
22 EA-9500B01-00 CABLE BAND 40
23 400-13197 CONVEYOR COUPLING 1
24 SM-8050502-TP SCREW M5 L=5 4
25 SL-6104042-TN BOLT 4
26 401-46963 BU_HOME_SENSOR_BR_ASM 1
27 EA-9500B01-00 CABLE BAND (1)
28 401-29042 AWC/BU ORG SENSOR CABLE ASM (1)
29 401-46994 BU_SENSOR_BR (1)
30 SM-4030801-SC SCREW M3X0.5 L=8 1
31
#03
401-
46989 WAIT_SENSOR_UNIT_L 1
32
#03
401-47013 WAIT_SENSOR_BR (1)
33 E2169-721-000 HOLD PLATE (1)
34 SL-6041292-TN SCREW (1)
35 401-35828 LR WAIT COUT SENS ASM (1)
36 SL-4031091-SC SCREW M3 L=10 (1)
- -
38.PWB CONVEYOR COMPONENTS(11)
7 5
A
6 2 6 3
7 4
7 3
6 4
7 1
6 9 7 0
6 8
6 7
4 7 4 8
5 5 5 6
7 2
6 6
6 5
6 1
3 8
4 1
4 0
3 9
4 4
4 5
4 2
4 3
6 0
5 8 5 9
5 4
5 7
5 2
5 3
6 0
5 8 5 9
4 6
2 0 2 1
1 0
9
6
1 2
2 3
1 6
1 3
8
1 3
7
A
A
5 1
1 9
1 8
2 9
2 8
2 7
3 1
2 2
2 6
2 7
3 4
3 0
3 4
3 1
3 7
3 5
2 4 2 5
3 2 3 3
1 1
1 5
1 4
1 2
5
3 6
7 6
3 4
4 9
5 0
7 7
B
B
1 7
