– 119 –
PANEL, FRAME SECTION
1907-005
No. Part No. Part Name Qty. Detail
201 KYA-M6503-00 FRAME_MONITOR 1
202 KYA-M6501-00 ASSY-OPE-PANEL 1
203 KYA-M6549-00 COVER_MONITOR 1
204 KYB-M6520-00 MONITOR_STOPPER 1
205 KYB-M6575-00 GROMMET 1
206 KYB-M651Y-00 HINGE_MONITOR 1
207 91312-08030 BOLT,HEX.SOCKET HEAD 1
208 95302-04600 NUT,HEXAGON 4
209 91312-04010 BOLT,HEX.SOCKET HEAD 4
210 90990-66J007 SCREW,TRUSS HEAD 4
211 92902-08200 WASHER,PLAIN 1
212 KYB-M651V-00 DISPLAY 1 N74
213 91312-06012 BOLT,HEX.SOCKET HEAD 2
214 92902-06200 WASHER,PLAIN 2
215 KYB-M6576-00 PROTECTION-TOOL 2
216 92902-04200 WASHER,PLAIN 4
