– 138 – G2 2 Nozzle Stocker Driving Section 1907-005 118 115 117 119 120 105 107 111 106 112 136 139 140 127 125 133 132 131 108 135 130 134 136 127 128 137 138 129 103 121 116 113 109 126 132 110 101 104 100 150 114

100%1 / 230
– 137 –
HIGH SPEED NOZZLE STOCKER
1907-005
No. Part No. Part Name Qty. Detail
4 KYA-M9624-00 ASSY SENSOR NST1 1 NST1
5 KYA-M9625-00 ASSY SENSOR NST2 1 NST2
6 KYA-M961N-00 ASSY MANIFOLD VALVE 1 NST4 ,5, 6
7 KYA-M960Y-00 STOPPER 2
11 KYB-M702T-00 PIPE_FITTINGS 1
12 KYB-M961N-00 PIPE_FITTINGS 1
13 91312-03025 BOLT,HEX.SOCKET HEAD 2
14 95302-03600 NUT,HEXAGON 2
15 91312-03004 BOLT,HEX.SOCKET HEAD 2
16 91312-03045 BOLT,HEX.SOCKET HEAD 4
17 91312-03025 BOLT,HEX.SOCKET HEAD 1
18 92902-03200 WASHER,PLAIN 1
19 90166-02J206 SCREW,PAN HEAD 4
20 90171-02J026 WASHER,PLAIN 4
21 90990-38J003 WASHER 4
22 KYB-M65AW-00 WIRING 1
23 90990-66J012 SCREW,TRUSS HEAD 1
27 91312-04035 BOLT,HEX.SOCKET HEAD 2
28 KYB-M962P-00 PIPE_FITTINGS 2
31 KYA-M9606-00 STOCKER_BASE 1
32 KYA-M9605-00 PLATE 1
33 KYA-M9614-00 L_BRACKET 2
35 91312-04010 BOLT,HEX.SOCKET HEAD 4
36 91312-04008 BOLT,HEX.SOCKET HEAD 4
38 92902-04200 WASHER,PLAIN 4
41 KYA-M7306-00 REJECT_BOX_BASE 1
42 KYA-M7305-00 REJECT_BOX 1
43 KYA-M7309-01 ASSY BH SENSOR 1
44 KYA-M730E-00 SHEET 1
45 90166-02J208 SCREW,PAN HEAD 2
46 91312-04008 BOLT,HEX.SOCKET HEAD 3
– 138 –
G2
2 Nozzle Stocker Driving Section
1907-005
118
115
117
119
120
105
107
111
106
112
136
139
140
127
125
133
132
131
108
135
130
134
136
127
128
137
138
129
103
121
116
113
109
126
132
110
101
104
100
150
114
– 139 –
HIGH SPEED NOZZLE STOCKER
1907-005
No. Part No. Part Name Qty. Detail
100 KYA-M9601-00 ASSY_CYLINDER 1
101 KYA-M960X-00 CYLINDER 1
103 KYA-M9612-00 OC_CYLINDER 1
104 KYA-M9608-00 AIR LINE EQPT 2
105 KYA-M960U-00 GUIDE 1
106 KYA-M9613-00 S_BRACKET 1
107 KYA-M960V-00 LEVER 1
108 KYB-M962D-00 PIN_HINGE 1
109 90933-01J693 BEARING_RADIAL 2
110 KYB-M963F-00 SPRING_TENSION 1
111 KYB-M961W-00 BRACKET 1
112 KYA-M960W-00 SPRING_BRACKET 1
113 KYA-M961D-00 BUSH_BEARING 1
114 KYB-M963E-00 SPRING_COMP 1
115 KYA-M960K-00 BLOCK 1
116 KYB-M962J-00 LEVER 1
117 KYB-M9627-00 PIN_HINGE 1
118 KYA-M9611-00 BRACKET 1
119 KYA-M9610-00 BRACKET 1
120 KYA-M960J-00 STOCKER_UNDER 1
121 KYA-M9615-00 SPEED_CONTROLLER 1
125 91312-03016 BOLT,HEX.SOCKET HEAD 2
126 90112-2AJ010 BOLT,HEX.SOCKET HEAD 2
127 91312-04008 BOLT,HEX.SOCKET HEAD 4
128 92902-04200 WASHER,PLAIN 2
129 90990-02J019 SCREW,SET 2
130 92902-04600 WASHER,PLAIN 1
131 91312-03008 BOLT,HEX.SOCKET HEAD 2
132 92902-03100 WASHER,SPRING 4
133 92902-03600 WASHER,PLAIN 2
134 90166-02J208 SCREW,PAN HEAD 1
135 90990-15J013 NUT_HEXAGON 1
136 91312-03006 BOLT,HEX.SOCKET HEAD 4
137 91312-04014 BOLT,HEX.SOCKET HEAD 2
138 90189-02J2A6 NUT,HEXAGON 1
139 92902-03200 WASHER,PLAIN 2
140 91312-03004 BOLT,HEX.SOCKET HEAD 1
150 KYA-M9623-00 HIGH-SPEED STOCKER 1
