– 163 – SIN GLE C ONVEY OR SE C TI ON 1907-005 No. Part No. Part Name Qty . Detail 100 KYY -M9100-00 ASSY_BASE 1 101 KYY -M910R-00 ASSY_MOTOR_W 1 101-01 KYB-M913X-00 MOTOR_STEPPING 1 M201 101-02 KYY -M913L-00 BRACKET_MOT…
– 162 –
H1
2 Base Section
1907-005
137
138
103
108
108
107
136
113
108
136
113
107
106
132
112
114
139
102-03
101-01
101-07
M201
B134
B135
B130
B131
B132
B201
B133
Y116
Y114
Y115
Y111
Y113
101-06
101-08
101-09
101-05
101
102
102
102
101-04
101-03
101-02
102-04
102-08
102-06
102-05
102-02
102-07
102-06
105-01
105-02
104
111
109
109
100
110
132
131
121
121
132
132
130
127
130
102-01
126
124
125
125
123
122
129
132
134
135
140
125
115
– 163 –
SINGLE CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
100 KYY-M9100-00 ASSY_BASE 1
101 KYY-M910R-00 ASSY_MOTOR_W 1
101-01 KYB-M913X-00 MOTOR_STEPPING 1 M201
101-02 KYY-M913L-00 BRACKET_MOTOR 1
101-03 KYA-M914V-00 PULEY_TIMING 1
101-04 KYY-M914T-10 ASSY_IDLER 1
101-05 KYA-M9155-00 SQUARE_NUT 1
101-06 90990-07J008 BOLT,HEXAGON 1
101-07 91312-04010 BOLT,HEX.SOCKET HEAD 2
101-08 90990-02J027 SCREW,SET 2
101-09 95302-04600 NUT,HEXAGON 1
102 KYY-M911S-00 ASSY_CYLINDER 1
102-01 KYA-M9128-00 ASSY-STOPPER1-SENSOR 1 B130, 132
102-02 KYA-M9129-00 ASSY-STOPPER2-SENSOR 1 B132, 133
102-03 KYA-M912A-00 ASSY-STOPPER3-SENSOR 1 B134, 135
102-04 KYA-M9169-00 BLOCK_STOPPER 3
102-05 KYA-M915E-00 BRACKET_CYLINDER 3
102-06 KYB-M702S-00 PIPE_FITTINGS 6
102-07 91312-04008 BOLT,HEX.SOCKET HEAD 18
102-08 KYA-M9197-00 BLOCK 1
104 KYY-M912D-00 ASSY-MANIFOLD-VALVE 1 Y111, 113-116
105-01 KYY-M910J-00 FRAME_UNDER 1
105-02 KYY-M910J-10 FRAME_UNDER 1
106 KYY-M9135-00 FRAME_CENTER 1
107 KYY-M9111-00 BASE 2
108 KYA-M9132-00 GUIDE_LINEAR_W 3
109 KYY-M913F-00 BRACKET_UNDER 2
110 KYY-M913G-00 PLATE_UNDER 1
111 KYA-M9154-00 DUCT 2
112 KYY-M915A-10 BLOCK 1
113 KYY-M911R-00 BRACKET 2
114 KYA-M9126-00 ASSY-ORG-SENSOR 1 B201
115 KYY-M915B-00 PLATE_STOPPER 1
121 90990-66J012 SCREW,TRUSS HEAD 8
122 91312-03035 BOLT,HEX.SOCKET HEAD 4
123 92902-03100 WASHER,SPRING 4
124 92902-03200 WASHER,PLAIN 4
125 91312-05014 BOLT,HEX.SOCKET HEAD 8
126 91312-05008 BOLT,HEX.SOCKET HEAD 8
127 98502-03006 SCREW,PAN HEAD 2
128 91312-03006 BOLT,HEX.SOCKET HEAD 2
129 91312-04008 BOLT,HEX.SOCKET HEAD 2
130 90990-66J011 SCREW,TRUSS HEAD 8
131 91312-05010 BOLT,HEX.SOCKET HEAD 4
132 91312-04016 BOLT,HEX.SOCKET HEAD 15
133 91312-06030 BOLT,HEX.SOCKET HEAD 2
134 97002-04014 BOLT,HEXAGON 1
135 95302-04600 NUT,HEXAGON 1
136 91312-04010 BOLT,HEX.SOCKET HEAD 4
137 KYY-M912B-00 FIBER SESOR12 ASSY 1
138 KYY-M912C-00 FIBER SESOR34 ASSY 1
139 KYC-M184S-00 SENSOR_PELEC 4
140 91312-03004 BOLT,HEX.SOCKET HEAD 8
