– 190 – H2 5 Fixed Chute L T ransport 1907-005 306 321 323 321 313 323 316 315 314 324 309 325 309 322 308 322 308 300 300 300 301 301 301 301 301 319 325 301 300 300 300 300 300 312 312 319 319 319 325 319 312 312 326 3…
– 189 –
DUAL CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
1 KYY-M914T-00 IDLER ASSY. 2
2 KYY-M914T-10 IDLER ASSY. 2
3 90990-01J128 BOLT,HEX.SOCKET HEAD 4
4 90933-03J698 BEARING_RADIAL 8
5 KYY-M914Y-00 COLLAR 6
6 KYY-M9133-00 BALL SCREW 2
7 KYA-M9157-00 SUPPORT_UNIT 2
8 KYA-M915R-00 PULLEY_TIMING 2
9 KYY-M915C-00 BLOCK 2
10 KYY-M9159-00 BLOCK 2
11 KYY-M9136-00 BLOCK 2
12 KYY-M915J-00 BRACKET 2
13 KYY-M910R-00 MOTOR-W ASSY. 2
14 KYB-M913X-00 MOTOR_STEPPING 2
15 KYY-M913L-00 BRACKET,MOTOR 2
16 KYA-M914V-00 PULEY_TIMING 2
17 KYA-M9155-00 SQUARE_NUT 2
18 KYA-M9126-00 ASSY-ORG-SENSOR 2
19 91312-06016 BOLT,HEX.SOCKET HEAD 4
20 91312-05016 BOLT,HEX.SOCKET HEAD 4
21 91312-05010 BOLT,HEX.SOCKET HEAD 4
22 91312-04010 BOLT HEX,SOCKET HEAD 4
23 91312-03010 BOLT HEX,SOCKET HEAD 4
24 91312-03006 BOLT,HEX.SOCKET HEAD 4
25 91312-03014 BOLT,HEX.SOCKET HEAD 8
26 91312-05008 BOLT,HEX.SOCKET HEAD 8
27 90990-07J008 BOLT,HEXAGON 4
28 90990-02J027 SCREW,SET 2
29 95302-04600 NUT, HEXAGON 2
30 98502-03006 SCREW,PAN HEAD 4
– 190 –
H2
5 Fixed Chute L Transport
1907-005
306
321
323
321
313
323
316
315
314
324
309
325
309
322
308
322
308
300
300
300
301
301
301
301
301
319
325
301
300
300
300
300
300
312
312
319
319
319
325
319
312
312
326
326
307
307
319
319
319
320
320
303
304
303
311
310
310
311
304
302
302
327
307
326
307
318
317
318
317
305
305
320
320
320
320
305
305
314
323
313
323
315
321
316
306
321
A LANE
B LANE
A LANE
B LANE
– 191 –
DUAL CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
300 KYB-M91AL-00 PULLEY_TIMING 8
301 KYY-M914U-A0 PULLEY_FLAT 8
302 KYY-M9152-20 TIMING BELT 2
303 KYY-M9115-40 BRACKET,BELT 2
304 KYY-M913D-40 BRACKET,BELT 2
305 KYY-M913B-00 BRACKET,BELT 4
306 KYY-M915V-20 BRKT.,GUIDE UNDER 1 2
307 KYB-M91C4-00 SPACER 4
308 KYY-M918X-20 BLOCK,CHUTE GUIDE 2 1
309 KLF-M9135-01 PLATE,EDGE 2 2
310 KYY-M9194-00 BRACKET 2
311 KYY-M9195-00 BRACKET 2
312 KYY-M912R-00 SENSOR,FIBER 4
313 KYA-M9124-00 ASSY-BOARD-SENSOR1 1 with SCREW.
314 KYY-M915M-20 BRACKET,SENSOR 2
315 KYY-M915K-20 BRACKET 2
316 KYY-M915N-20 BRACKET,SENSOR 2 2
317 KYY-M9138-20 PLATE 2
318 90990-01J127 BOLT,HEX.SOCKET HEAD 12
319 91312-03006 BOLT,HEX.SOCKET HEAD 8
320 91312-03004 BOLT,HEX.SOCKET HEAD 18
321 91312-04006 BOLT,HEX.SOCKET HEAD 8
322 91312-04016 BOLT,HEX.SOCKET HEAD 4
323 90990-01J136 BOLT,HEX.S/H WW 6
324 98702-03006 SCREW, FLAT HEAD 8
325 95302-05600 NUT, HEXAGON 2
326 90990-02J019 SCREW,SET 4
