– 207 –
DUAL CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
1 KYY-M919T-00 MOTOR ASSY. 2
2 KYB-M917X-00 MOTOR_STEPPING 2
3 KYB-M91BP-00 PULLEY_TIMING 2
4 90990-02J026 SCREW,SET 4
5 KYY-M919U-00 PULLEY FIX ASSY. 2
6 KYB-M91AY-00 PULLEY_TIMING 2
7 KYY-M91E2-00 SHAFT,SPLINE 2
8 90990-02J024 SCREW,SET 4
9 KYY-M919V-00 PULLEY MOVE ASSY. 2
10 KYY-M91AX-00 PULLEY,TIMING 2
11 KLW-M9108-01 COLLAR,CONVEYOR 2
12 90990-41J176 COLLAR 8
13 KYB-M91AU-00 PULLEY_TIMING 2
14 KYB-M91BA-00 BELT_TIMING 2
15 KH2-M9121-00 BEARING 4
16 KYY-M91E3-00 SPLINE 2
17 KYY-M91E1-31 BRACKET,MOTOR-L 2
18 KYY-M91E5-30 BRKT.,SPLINE-L 2
19 KYY-M91E6-31 BRACKET,FIX-L 2
20 90990-41J006 COLLAR 2
21 91312-04008 BOLT,HEX.SOCKET HEAD 8
22 91312-03008 BOLT HEX,SOCKET HEAD 16
23 91312-03010 BOLT HEX,SOCKET HEAD 4
24 91312-04014 BOLT HEX,SOCKET HEAD 4
25 95302-04600 NUT, HEXAGON 4
26 90990-02J026 SCREW,SET 4
27 91312-04006 BOLT,HEX.SOCKET HEAD 8
28 92902-04600 WASHER,PLAIN 8
29 91312-04010 BOLT HEX,SOCKET HEAD 2
