– 214 – H2 17 Cable 1 1907-005 B136 B302 B201 B301 B304 B303 B140 B130,131 B132,133 B134,135 B201 B130,131 B132,133 B134,135 B141 B305 B306 B136T 614 615 B302 B301 B304 B303 B140 B141 B305 B306 614 615 611 611 617 616 B1…
– 213 –
DUAL CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
501 KYA-M915W-00 TUBE_D4 1
502 KYA-M915X-00 TUBE_D32 1
503 KYB-M919J-00 TUBE_D6 1
– 215 –
DUAL CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
611 KYA-M910P-00 HNS,CONV-IO-U 1
614 KYA-M911B-00 HNS,SLOW-SENSOR1 1
615 KYA-M911C-00 HNS,SLOW-SENSOR2 1
616 KYA-M911D-00 HNS,BU-PIN-SENSOR-R 1
617 KYA-M911E-00 HNS,BU-PIN-SENSOR-T 1
641 KYY-M911A-00 PANEL 1
642 KYB-M91AK-00 PCB-MOUNT 1 U08(UB95)
644 KYB-M913W-00 UNIT-DRIVER 1 A41
645 90990-11J012 SCREW,PAN HEAD WW 4
646 90990-11J017 SCREW,PAN HEAD WW 4
648 KYY-M911L-00 HNS,CONV-INTL-D 1
649 KYY-M910N-00 HNS,CONV-IO-D 1
