– 26 – B1 4 O/C Door LR 1907-005
– 25 –
COVER SECTION
1907-005
No. Part No. Part Name Qty. Detail
203 KYY-M1304-00 F_GUL_MIDDLE_ASSY 1
204 KYA-M131F-00 GUL_COV_AS_A 1
205 KYA-M131P-00 GUL_COV_AS_B 1
206 KYA-M132L-00 LOCK_KEY_BRA_A 1
207 KYA-M132J-00 LOCK_KEY_BRA_B 1
208 KYA-M1335-00 ACCESS_SW_(KEY) 1
209 90990-01J145 BOLT,HEX.S/H WW 4
210 90990-01J144 BOLT,HEX.S/H WW 6
211 90990-01J140 BOLT,HEX.S/H WW 14
212 90990-06J011 BOLT,BUTTON HEAD 4
213 92902-04100 WASHER,SPRING 4
214 92902-04200 WASHER,PLAIN 4
221 KYY-M130A-10 F_GUL_MIDDLE 1
222 KYA-M131K-00 COVER_F_GUL_MIDDLE 1
223 KYA-M131L-00 COVER 2
224 KYA-M131M-00 COVER 2
225 KYA-M132B-00 STAY 1
226 KYA-M131B-00 GUM_CUSHION 2
227 KYA-M131D-00 GUM_CUSHION 1
228 KYY-M130M-10 BRKT,GUL GUARD-R 1
229 KYA-M132H-00 SET_SCREW 2
230 90990-11J010 SCREW,PAN HEAD WW 11
231 90990-01J139 BOLT,HEX.S/H WW 18
232 91312-05012 BOLT,HEX.SOCKET HEAD 3
233 91312-04008 BOLT,HEX.SOCKET HEAD 8
234 92902-04200 WASHER,PLAIN 8
235 95302-06600 NUT,HEXAGON 2
236 92902-06100 WASHER,SPRING 2
237 92902-06200 WASHER,PLAIN 2
238 92902-05200 WASHER,PLAIN 3
239 KYA-M132K-00 PLATE 2
241 KYY-M1305-00 F_GULCOVER_ASSY_YG 2 ALL PARTS
242 KYY-M1300-00 F_GUL_SIDE_L_A 1
243 KYY-M1301-00 F_GUL_SIDE_R_A 1
– 27 –
COVER SECTION
1907-005
No. Part No. Part Name Qty. Detail
301 KYB-M134H-00 COVER_GUL_SIDE_L 1
302 KYA-M131A-00 GUM_CUSHION 1
303 KYA-M131C-00 GUM_CUSHION 1
304 KYA-M132E-00 REAR_BLOCK_B 1
305 KYA-M132C-00 UNDER_BLOCK_L 1
306 90990-11J015 SCREW,PAN HEAD WW 4
307 90990-11J010 SCREW,PAN HEAD WW 9
308 90990-66J010 SCREW,TRUSS HEAD 2
309 KYC-M174N-00 MG_CATCH_C9302 1
311 KYB-M134J-00 COVER_GUL_SIDE_R 1
312 KYA-M131A-00 GUM_CUSHION 1
313 KYA-M131C-00 GUM_CUSHION 1
314 KYA-M132D-00 REAR_BLOCK_A 1
315 KYA-M132F-00 UNDER_BLOCK_R 1
316 90990-11J015 SCREW,PAN HEAD WW 4
317 90990-11J010 SCREW,PAN HEAD WW 9
318 90990-66J010 SCREW,TRUSS HEAD 2
319 KYC-M174N-00 MG_CATCH_C9302 1
