– 39 –
FEEDER CART SECTION
1907-005
No. Part No. Part Name Qty. Detail
402 KYB-M372S-00 BLOCK 1
403 91312-05012 BOLT,HEX.SOCKET HEAD 3
405 KYB-M3735-00 MECH_PARTS 2
407 KYB-M372C-00 GUIDE_SHAFT 1
408 91312-05025 BOLT,HEX.SOCKET HEAD 2
410 98502-03006 SCREW,PAN HEAD 2
411 KYA-M370M-00 ASSY_VALVE-L 1
411-01 KYA-M370G-00 ASSY-VALVE-L 1
411-02 KYB-M3725-00 PIPE_FITTINGS 1
411-03 $AN120-M5 AIR_LINE_EQPT 2
412 KYA-M371E-00 HOOK_L 1
413 92012-03006 BOLT,BUTTON HEAD 2
416 91312-03016 BOLT,HEX.SOCKET HEAD 4
417 KYA-M370R-00 ASSY_SHAFT_L 1
417-01 KYA-M370V-00 SHAFT 1
417-02 KYA-M371K-00 PLATE 1
417-03 90440-01J070 E_RING 2
417-04 KYA-M3719-00 BLOCK 2
417-05 KYA-M371J-00 BUSH_BEARING 2
417-06 91312-03006 BOLT,HEX.SOCKET HEAD 3
417-07 KYA-M371B-00 PLATE_ARM-L 1
417-08 KYA-M370Y-00 CAM_FOLLOWER 1
417-09 KYA-M371C-00 SPACER 1
417-10 95302-03600 NUT,HEXAGON 1
417-11 90112-2AJ006 BOLT,HEX.SOCKET HEAD 2
418 KYA-M371F-00 SPLING_TENSION 1
420 KYA-M371M-00 GUIDEBLOCK-L 1
421 91312-04008 BOLT,HEX.SOCKET HEAD 4
422 KYA-M370K-00 ASSY_CYLINDER_L 1
422-01 KYA-M370J-00 ASSY-SENSOR-L 1
422-02 KYA-M3710-00 SPEED_CONTROLLER 2
422-03 KYA-M371G-00 ROD 1
422-04 95302-05600 NUT,HEXAGON 1
422-05 KYA-M371H-00 BRACKET_CYLINDER 1
422-06 91312-06016 BOLT,HEX.SOCKET HEAD 4
422-07 92902-06200 WASHER,PLAIN 4
423 KYA-M3714-00 BASE 1
424 KYA-M3712-00 FLAT_SPRING 1
425 91312-03008 BOLT,HEX.SOCKET HEAD 5
426 KYA-M3713-00 FLAT_SPRING 1
427 KYA-M371L-00 FLAT_SPRING 2
428 KYB-M850P-00 TUBE D6 1
429 KYB-M961G-00 TUBE D6 1
430 92902-05200 WASHER,PLAIN 4
431 91312-05016 BOLT,HEX.SOCKET HEAD 4
