– 75 –
DC POWER SUPPLY SECTION
No. Part No. Part Name Qty. Detail
201 KYA-M655S-00 PANEL 1
202 KYB-M658N-00 CABLE-JOINT-TERMINAL 3
203 KYB-M852B-00 CASE-CONN 1
204 KYB-M6588-00 TUBE-WIRING 1
205 KYA-M410A-00 TUBE_WIRING 1
206 KYB-MD73A-00 TUBE_WIRING 1
207 KYB-M852E-00 ACCESS-WIRING 1
209 KYA-M6567-00 MOTOR-DC 1 M106
210 KYB-M65AM-00 ACCESSORY-MOT-M 2
211 KYA-M656G-00 ACCESSORY-MOT-M 1
212 KYB-M410J-00 FAN_SUPPORT 1
213 90990-09J012 SCREW,FLAT HEAD 4
214 92902-04200 WASHER,PLAIN 4
215 95302-04600 NUT,HEXAGON 4
1907-005
