– 79 –
AIR SUPPLY SECTION
1907-005
No. Part No. Part Name Qty. Detail
10 KYY-M132C-A0 BOLT,HEX.SOCKET HEAD 4
11 KYA-M850A-00 RUBBER_PAD 4
21 91312-04008 BOLT,HEX.SOCKET HEAD 8
22 91312-04025 BOLT,HEX.SOCKET HEAD 4
23 91312-05008 BOLT,HEX.SOCKET HEAD 4
24 91312-05012 BOLT,HEX.SOCKET HEAD 2
25 92902-05600 WASHER,PLAIN 6
26 KYB-M65AA-00 ROHS_WASHER 8
31 KYB-M850T-00 PIPE_FITTINGS 6
32 KYB-M850X-00 PIPE_FITTINGS 4
33 KYB-M8514-00 PIPE_FITTINGS 1
34 KYB-M8515-00 PIPE_FITTINGS 6
35 KYB-M8517-00 PIPE_FITTINGS 3
36 KYB-M8516-00 PIPE_FITTINGS 5
37 KYA-M850L-00 PIPE_FITTINGS 2
38 KYB-M852A-00 PIPE_FITTINGS 1
41 KYA-M850P-00 TUBE_D6 1
42 KYA-M850T-00 TUBE_D8 1
43 KYA-M850R-00 TUBE_D10 1
44 KYA-M850S-00 TUBE_D6_BU 1
45 KYA-M850U-00 TUBE_D8_BU 4
46 KYB-M850M-00 TUBE_D10_BU 1
51 KYB-M8519-00 CORD-DVI-5M 1
52 KYB-M851A-00 CORD-USB-A-A 1
53 KYB-M658H-00 ACCESS-WIRING 2
61 KYB-M8503-00 FRAME(LOWER) 1
62 KYB-M851B-00 BOLT_CONNECT 4
63 KYB-M851C-00 NUT_CONNECT 4
64 KYY-M851F-00 LEVELING BOLT ASSY 4
– 80 –
D5
2 Air Combination Unit, Vaccum Pump
1907-005
tooltip
124
112
124
134
126
122
123
113
131
132
133
125
114
111
See Fig. D5-1
M66
S141
Key No.11,26
See Fig. D5-1
Key No.61
11
127
119
125
121
123
120
116
145
147
146
144
143
142
141
151
141
152
104
105
101
103
102
135
5
– 81 –
AIR SUPPLY SECTION
1907-005
No. Part No. Part Name Qty. Detail
101 KYB-M850F-00 AIR_LINE_EQPT 1
102 KYB-M8520-00 PIPE_FITTINGS 1
103 $KK130P-02MS AIR_COUPLER_PLUG 1
104 KYB-M8512-00 PIPE_FITTINGS 1
105 KYB-M8506-00 ASSY_AIR-SUP-1 1
111 KYB-M851Y-00 VACUUM_PARTS 1
112 KYB-M850G-00 AIR_LINE_EQPT 1
113 KYB-M8505-00 ASSY_SWITCH 1 S141
114 KYB-M851W-00 AIR_LINE_EQPT 1
115 KYB-M850B-00 PLATE_AIR-SUP 1
116 KYB-M850H-00 REGULATOR 1
119 KYB-M850W-00 PIPE_FITTINGS 2
120 KYB-M8510-00 PIPE_FITTINGS 1
121 KYB-M711J-00 PIPE_FITTINGS 1
122 KYB-M8524-00 PIPE_FITTINGS 1
123 KYB-M8526-00 PIPE_FITTINGS 2
124 KYB-M851L-00 PIPE_FITTINGS 2
125 KYB-M850P-00 TUBE_D6 1
126 KYA-M850N-00 TUBE_D8 1
127 90990-11J022 SCREW,PAN HEAD WW 4
131 KYB-M852C-00 CASE-CONN 1
132 KYB-M852D-00 CASE-CONN 1
133 KYB-M852F-00 CONNECTOR 1
135 98502-03008 SCREW,PAN HEAD 4
141 KYB-M8518-00 VACUUM_PUMP 1 M66
142 $MBA1403 PIPE_FITTINGS 1
143 KYB-M8521-00 PIPE_FITTINGS 3
144 $MPG14 PIPE_FITTINGS 1
145 KYA-M850J-00 PIPE_FITTINGS 1
146 KYA-M850K-00 AIR_LINE_EQPT 1
147 KYB-M850M-00 TUBE_D10_BU 1
151 KYA-M8508-00 HNS,PUMP1 1
152 KYA-M8502-00 ASSY_V-PUMP 1
