Door Cover
Cover
KLS-1303
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
90166-02J203 SCREW, PAN HEAD 2 39 90990-06J002 BOLT,BUTTON HEAD 2
M4
/
Í
2
90167-02JA05 SCREW, FLAT HEAD 2
40 92902-04200 WASHER,PLAIN 14
M4
3
90990-01J074 BOLT HEX,SOCKET HEAD 2 41 95302-04600 NUT HEXAGON 2
4
90990-33J026 BOLT, STOPPER 2 42 98702-03005 SCREW,FLAT HEAD 12
5
90990-46J016 BOLT, THIN HEAD 4 43 92902-03200 WASHER,PLAIN 6
6
90K41-001250 LABEL,WARNING
1
44
7
91312-03004
BOLT HEX,SOCKET HEAD 2
45
8
91312-03005
BOLT HEX,SOCKET HEAD 4
46
9
91312-03006 BOLT HEX,SOCKET HEAD 6
47
10
91312-04008 BOLT HEX,SOCKET HEAD 12 48
11
91317-03006 BOLT HEX,SOCKET HEAD 4 49
12
91317-03012 BOLT HEX,SOCKET HEAD 6 50
13
KW7-M5127-00 SAFETY SWITCH KEY 1
/
Í
51
14
90K41-001260 LABEL,WARNING 1
/
52
15
KGS-M1360-00 BOLT 2
/
Í
53
16
KH2-M1324-01 GRIP 1
/
54
17
KL0-M1374-00 PLATE 1, SCHMEASAL
1
/
Í
55
18
KLS-M13C1-01
DOOR 1
M4
/
56
19
KLS-M13C2-00
BRKT.,SPRING 1
/
57
20
KLS-M13C3-00 PLATE,GUIDE 1
/
58
21
KLS-M13C4-00 RAIL 2
/
59
22
KLS-M13C5-00 BRKT.,RAIL R 1
/
60
23
KLS-M13C6-00 BRKT.,RAIL L 1
/
61
24
KLS-M13C7-00 SHAFT,SPRING 2
/
62
25
KLS-M13C8-00 BUSH 4
/
63
26
KLS-M13C9-00 SPRING 2
/
64
27
KLS-M13CA-11 BRKT.,KEY 1
M4
/
Í
65
28
KLS-M13CB-00 BRKT.,HINGE 2
/
Í
66
29
KLS-M13CC-00 HINGE 2
/
67
30
KLS-M13CD-00 BRKT.,LATCH 1
/
68
31
KLS-M13CE-00 LATCH 1
/
69
32
KLS-M13CG-00 PLATE,LATCH 1
/
70
33
KLS-M13CH-00 STAY,R 1
/
Í
71
34
KLS-M13CJ-00 STAY,L 1
/
Í
72
35 KLS-M13CK-00 MAG,CATCH 1
/
73
36
KLS-M13CM-00 GUIDE,RACK DOOR 1 2
/
74
37 KLS-M13CN-00 GUIDE,RACK DOOR 2 1
/
75
38 KLS-M13CP-00 GUIDE,RACK DOOR 3 1
/
76
2
2
Door Cover
Cover
KLS-1402
38
40
7
20
44
26
14
2
3
3
30
17
6
9
31
27
33
3
29
3
13
10
21
24
15
13
18
41
32
39
23
1
25
11
28
44
3
43
38
5
7
34
35
3
12
8
36
12
4
16
19
37
20
38
4
8
42
22
3
1
FDR.Holder
Feeder holder
