Rack lock
Magazine
KLS-1303
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
90947-30JA00 BALL STEEL 4
39
2
91312-03005 BOLT HEX,SOCKET HEAD 16
40
3
91312-03008 BOLT HEX,SOCKET HEAD 10
41
4
91312-04005 BOLT HEX,SOCKET HEAD 6
42
5
92012-03005 BOLT BUTTON HEAD 2
43
6
92012-04006
BOLT, BOTTON HEAD 1
44
7
92012-04010 BOLT, BOTTON HEAD
14
45
8
92902-03200
WASHER,PLAIN 4
46
9
KGT-M9224-00 STOPPER,BUSHING 6
/
47
10
KGX-M1787-01 LEAF SPRING 4
A
Í
48
11
KGX-M1792-00 HOLDER 1,SHAFT 2 /
49
12
KGX-M1793-00 SHAFT,LOCK 3 /
50
13
KGX-M1794-00 HOLDER 3,SHAFT 2
/
Í
51
14
KGX-M1795-01 NAIL,LOCK 2 /
52
15
KGX-M1796-00 BRACKET,SENSOR 2 /
53
16
KGX-M1797-00 SHAFT,STOPPER 2
/
Í
54
17
KGX-M1798-00
WASHER 3
/
55
18
KGX-M1799-00 LINER BALL BUSH
3
/
56
19
KGX-M179B-00 BUSH
2
/
Í
57
20
KGX-M179C-00 LEVER 3 /
58
21
KGX-M179D-00 SPG. 2 A
59
22
KLS-M19E1-00 HOLDER 2,SHAFT 1 /
Í
60
23
KLS-M19E2-00 HOLDER,SHAFT 3 1
/
Í
61
24
KLS-M19E3-00 SPRING 1 A
62
25
KLS-M19E4-00 BUSH 1
/
Í
63
26
KLS-M19E5-00 BRACKET,SENS. 1 /
64
27
KLS-M19E6-02 BASE,LOCK 1 /
Í
65
28
KLS-M19F1-01 BASE,LOCK 2 /
Í
66
29
KLS-M653E-31 SEN.SUP.CLAMP ASSY 1
B
Í
67
30
KLS-M653E-40 SEN.MGZ1 CLAMP ASSY 1
B
Í
68
31
KLS-M653E-50 SEN.MGZ2 CLAMP ASSY 1
B
Í
69
32
KM5-M7169-00 SCREW 4 /
Í
70
33
98902-03008 SCREW BINDING HEAD 3 71
34
99480-03012 PIN,PARALLEL 1 72
35
73
36
74
37
75
38
76
9
4
Rack lock
Magazine
KLS-1404
16
1
1
12
1
2
14
13
15
8
8
9
17
3
7
6
4,5
4,5
10
11
2
10
1
Exterior
Exterior, etc
