Installation Manual SIPLACE Setup Center RF 2.1 3 Installation
Edition 09/2005 EN 3.3 Installation of SIPLACE Setup Center and Possible Setup Types
35
Step 4
→ In the DB Initialization dialog box you enter the information required to be connected with the
SQL Server and database.
→ The figure you enter in the MB text box defines the size of the SIPLACE Setup Center data-
base files (default: 50) which are to be created during the installation.
→ Confirm the default value or enter the size you want in the MB text box.
3
Fig. 3.3 - 24 "DB Initialization" dialog box
Note
The specified size is only an initial value. The database will grow automatically as required.
However, only the database administrator is capable of freeing up unused disk space.
In the "database files" edit field, enter the directory in which the SIPLACESetupCenter.mdf file is
to be created. In the transaction log files edit field, enter the name of the directory in which the
SIPLACESetupCenter.mlf database file is to be created. 3
3 Installation Installation Manual SIPLACE Setup Center RF 2.1
3.3 Installation of SIPLACE Setup Center and Possible Setup Types Edition 09/2005 EN
36
Step 5
→ The Start Copying Files dialog box gives you a last chance to check the information you have
entered during the previous steps.
3
Fig. 3.3 - 25 "Start Copying Files" dialog box
→ Click Next if you accept all the information entered so far.
→ If you want to alter one or more details, click the Back button until you get back to the dialog
box in question.
→ There, enter your changes and click Next to continue as usual.
3
Installation Manual SIPLACE Setup Center RF 2.1 3 Installation
Edition 09/2005 EN 3.3 Installation of SIPLACE Setup Center and Possible Setup Types
37
Step 6
→ The installation routine is now started.
The Setup Complete dialog box confirms that the installation has been completed success-
fully. 3
3
Fig. 3.3 - 26 "InstallShield Wizard Complete" dialog box
→ Click Finish.
