3.3.3.9 Bind or Join the scanner to a RF station
You can connect more than one scanner to one RF station. With the first scanner you need to scan
the barcode label Bind, with all further scanners you need to scan the barcode label Join. 3
Please follow one of the following instructions according to your choice. 3
3
Note
You can never recognize if the Dragon scanner has the configuration Bind or Join. Therefore
please note your configuration you did. If you do not remember your configuration you have to
configure it once again. 3
Bind
→ Make sure the RF station is on (yellow
light is on).
→ When scanning the following barcode
the green LED of the scanner is active for
about 10 seconds. Put the scanner into
the RF station during these 10 seconds.
Join
→ The following barcode may be used to
add further scanners to one RF station.
→ Keep in mind that the first scanner need
to be bound to the station as described
on the left side. Each scanner must be
set to a unique address (see “Setting of
the Scanner Address” on page 42).
The connection can be tested by scanning
any barcode with the scanner. After the scan-
ning, the yellow LED ”power/data” is
switched off for 0.5 seconds.
Bind
Join
Installation Manual SIPLACE Setup Center RF 2.1 3 Installation
Edition 09/2005 EN 3.3 Installation of SIPLACE Setup Center and Possible Setup Types
45
3.3.3.10 RF Station Communication Configuration
The following barcodes are required to set up the RF station and activates the RF station serial
communication to the PC. 3
3
3
3.3.4 Testing the Setup
→ Connect the RF station to the Setup Center PC to the COM interface.
→ Make sure, the RF station is on (yellow LED is active).
→ If Setup Center is already running open the configuration dialog, otherwise start Setup Center.
→ Select the COM port in the configuration dialog of SIPLACE Setup Center and apply settings.
→ Press successively all three buttons on the scanner.
→ Now the main menu text SIPLACE Setup Center is displayed on the scanner.
Restore OM-DRAGON™ default
