6 Uninstalling
6.1 Backup Configuration Files
Copy all .xml files from the "\Program Files\Siemens SIPLACE\Setup Center" directory to a save
location. 6
It is recommended that the unsupported tool Configuration backup and recovery is used to
back up the SIPLACE Setup Center configuration before uninstalling the software. 6
6.2 Uninstalling the Software
Uninstalling SIPLACE Setup Center deletes all SIPLACE Setup Center software components
from the system except for the SIPLACE Setup Center database. 6
The SIPLACE Setup Center database is not automatically uninstalled in order to prevent possible
data loss. 6
6.2.1 Step 1
Uninstall SIPLACE Setup Center via the Control Panel. 6
You require the uninstall window in Windows for uninstalling. 6
→ Click Start in the Windows start menu.
→ Click Settings.
→ Click Control Panel.
→ Double-click Add / Remove Programs.
A list appears with the names of the software packages installed on the computer. 6
→ Select SIPLACE Setup Center.
→ Click the Change/Remove components button.
→ In the Confirm File Deletion dialog box, click Yes if you wish to proceed or No if you wish to
cancel the uninstall process.
→ Select Remove to remove all installed features.
→ Click Next to continue.
→ In the Confirm File Deletion dialog box, click OK if you wish to proceed or Cancel if you wish
to cancel the uninstall process.
→ Click Next and you get a summary of all components to be deleted.
6 Uninstalling Installation Manual SIPLACE Setup Center RF 2.1
6.3 Uninstalling the Database Edition 09/2005 EN
56
→ Click Next if you accept all the information entered so far.
→ Click Done.
6.2.2 Step 2
Clean up the disk and make sure that there are no more program files. 6
→ Check the path Program Files\Siemens SIPLACE\SIPLACE Setup Center.
→ If you will find additional files, please delete them (except for the database files with extensions
.mdf and .ldf).
6.3 Uninstalling the Database
The database can be uninstalled with the Microsoft SQL Server 2000 Enterprise Manager. 6
→ Expand the node Microsoft SQL Servers
→ Expand the node SQL Server group
→ Expand the node of the database server instance on which the SIPLACE Setup Center data-
base was installed to.
→ Expand the node Microsoft SQL Servers
→ Expand the node Databases
→ Right click the node SIPLACESetupCenter and select Delete.
→ Confirm the deletion of the database.
6
→ Go back to the node of the database server instance.
→ Expand the node "Management"
→ Expand the node "SQL Server Agent"
→ Expand the node "Jobs"
→ Mark all entries starting with "SIPLACESetupCenter" and delete them.
→ Confirm the deletion of the maintenance jobs.
→ Go back to the node of the database server instance.
→ Expand the node Security
→ Expand the node Logins
→ Mark all entries starting with SIPLACESetupCenter and delete them.
→ Confirm the deletion of the logins.
The database is completely deleted now. 6
The ServerManager is an unsupported tool that is able to create, empty and delete the SIPLACE
Setup Center database. The password for the user 'sa' is required. 6
