User manual SIPLACE SX1/SX2 3 Technical data and assemblies From software version SC 706.1 SP1 Version 10/2014 3.5 Placement head 111 3.5.4 SIPLACE MultiS t ar CPP 3 Fig. 3.5 - 3 SIPLACE MultiSt ar - front view, function…
3 Technical data and assemblies User manual SIPLACE SX1/SX2
3.5 Placement head From software version SC 706.1 SP1 Version 10/2014
110
3.5.1.3 Sensor for the component reject bin
3
3.5.2 Vacuum pump
3.5.2.1 Safety instructions for vacuum pumps
3
3.5.3 Description
Each Collect&Place head has its own vacuum generator, which supplies the holding and place-
ment circuit with the required vacuum. The vacuum generator for the placement heads functions
according to the Venturi principle. When operated together with a vacuum pump, the compressed
air consumption for the SpeedStar (C&P20) head can be reduced considerably. A vacuum pump
can supply up to two SpeedStar (C&P20) heads. Only one vacuum pump can be used at a time.
The running costs will fall according to the energy costs incurred.
3
3
PLEASE NOTE
When using a SpeedStar we recommend that you install the optional sensor for the com-
ponent reject bin. (See also section 6.7
, page 333)
WARNING
Please observe the safety instructions in the user manual supplied.
PLEASE NOTE
The compressed air consumption values can be found in section 3.2.4
, page 98.
User manual SIPLACE SX1/SX2 3 Technical data and assemblies
From software version SC 706.1 SP1 Version 10/2014 3.5 Placement head
111
3.5.4 SIPLACE MultiStar CPP
3
Fig. 3.5 - 3 SIPLACE MultiStar - front view, function groups part 1
(1) Star with 12 segments
(2) Segment with integrated DP drive
(3) Torque motor for star drive
(4) Intermediate distributor board
(5) Control board for 12 DP drives
(6) Compressed air connection for the Venturi nozzles in the pickup/placement and holding cir-
cuit
3 Technical data and assemblies User manual SIPLACE SX1/SX2
3.5 Placement head From software version SC 706.1 SP1 Version 10/2014
112
3
Fig. 3.5 - 4 SIPLACE MultiStar - front view, function groups part 2
(1) C&P component camera, type 30, 27 x 27, digital
(2) Torque motor for star drive
(3) Z drive (linear motor)
(4) Return cylinder
(5) Pressure control valve
