5.6.4 Context-sensitive online help
To see information about the current view, click on the icon to start the help system for the
station computer. The main window of the help system will open with alert information. The infor-
mation refers to the view currently shown and from which the help function was started. Use the
list of contents, index and the search function to view the contents of the Online Help.
User manual SIPLACE SX1/SX2 5 Working with the machine
From software version SC 706.1 SP1 Version 10/2014 5.7 Indicator lamps with horn
247
5.7 Indicator lamps with horn
5.7.1 Overview
These indicator lamps are used to signal operating statuses and malfunctions of the machine.
The horn
indicates when an alert has occurred. SIPLACE machines can either be fitted with a two or three
color indicator lamp.The relevant indicator lamp system (two or three color) is set in the autocon-
figuration, see installation guide for station software, Item No. 00196771-xx.
5.7.1.1 Two color indicator lamp (standard)
Fig. 5.7 - 1 Indicator lamps for operating states
L1 left indicator lamp
L3 right indicator lamp
T Direction of PCB transport
(L1)
(L2)
5 Working with the machine User manual SIPLACE SX1/SX2
5.7 Indicator lamps with horn From software version SC 706.1 SP1 Version 10/2014
248
5.7.1.2 Three color indicator lamp (optional)
Fig. 5.7 - 2 Indicator lamps for operating states
L1 red indicator lamp
L2 yellow indicator lamp
L3 green indicator lamp
(L2)
(L1)
(L3)
