User manual SIPLACE SX1/SX2 5 Working with the machine From software version SC 706.1 SP1 Version 10/2014 5.7 Indicator lamps with horn 251 5.7.2.1 Basics 5 5.7.2.2 Frequency of flashes 5 5 5.7.2.3 Priorities 5 5.7.2.4 R…
5 Working with the machine User manual SIPLACE SX1/SX2
5.7 Indicator lamps with horn From software version SC 706.1 SP1 Version 10/2014
250
The nozzle setup is not com-
plete.
Respective side White: 500 -500
Green: --
Red: Off
Yellow: On
Green: On
The last available pickup posi-
tion is being used or there is no
pickup position left for this com-
ponent. The machine will con-
tinue to produce while there are
still other components which
can be placed.
Respective side White: 100 -200
Green: --
Red: Off
Yellow: On
Green: On
The filling level of the pickup
position or dipping module is
low.
Respective side White: 100 -200
Green: --
Red: Off
Yellow: On
Green: On
Unable to move one of the
boards to the next area.
Respective side White: On
Green: --
Red: Off
Yellow: 500 - 500
Green: Off
Unable to read the board bar-
code in the input conveyor. The
operator must insert the board
manually.
Respective side Not configured Red: Off
Yellow: 500 - 500
Green: Off
The machine has been auto-
matically stopped due to a non-
configured event e.g. conveyor
error
. Events which have not been
configured and which could
lead to a machine stop have not
be taken into consideration
here.
Both sides White: On
Green: Off
Red: Off
Yellow: 500 - 500
Green: Off
The production has been auto-
matically stopped (e.g. there is
no component ready for pick-
up).
Respective side White: On
Green: Off
Red: Off
Yellow: 500 - 500
Green: Off
The machine is performing a
manual function triggered by
the operator.
White: 100 -1000
Green: 700 - 700
Red: Off
Yellow: Off
Green: 500 - 500
The machine has been stopped
due to a fiducial measurement
error ( z. B. board, table, feeder
module).
Both sides White: On
Green: Off
Red: Off
Yellow: 500 - 500
Green: Off
The safety loop has not closed. Respective side White: On
Green: Off
Red: On
Yellow: Off
Green: Off
Meaning Machine side Status - two color
(white/green)
Status - three color
(red/yellow/green)
User manual SIPLACE SX1/SX2 5 Working with the machine
From software version SC 706.1 SP1 Version 10/2014 5.7 Indicator lamps with horn
251
5.7.2.1 Basics
5
5.7.2.2 Frequency of flashes
5
5
5.7.2.3 Priorities
5
5.7.2.4 Reaction time
Each change to the machine status is shown at the indicator lamps within three seconds.
Status Meaning
Off No warning and no alert
Flashes Warning, the frequency varies depend on the type of warning on/
off in milliseconds.
On Alert
-- The described state does not affect the lamp concerned.
Normal flashing Green indicator lamp: 700 ms off, 700 ms on
White indicator lamp: 500 ms off, 500 ms on
Short flashing 100 ms off, 1000 ms on
Fast flashing 100 ms off, 200 ms on
Type of warning Priority
Definition for fast flashing Top
Definition for normal flashing Medium
Definition for short flashing Lowest
5 Working with the machine User manual SIPLACE SX1/SX2
5.8 Shift changeover From software version SC 706.1 SP1 Version 10/2014
252
5.8 Shift changeover
5.8.1 Shift changeover tasks
Splice the tapes early. The feeder modules do not have to be refilled as soon as the new shift
starts. This minimizes extended down times.
At the shift change, pass important information on to the next operator. This includes, for in-
stance, changes to the placement program. Also read through the list of the descriptions of
the steps to take in section 5.12
, page 275.
Carry out a setup check.
Make sure that the feeder modules are equipped with the correct components, that they are
at the correct locations in the component trolley and that the conveyor increment is set cor-
rectly.
Clean the following line assemblies:
Empty the reject bin and carefully vacuum the area around the reject bin.
Carefully vacuum the nozzle changer, feeder modules and the component trolley.
Empty the waste tape container. Follow the safety instructions given in section 5.8.2, page
253
.
Empty the tray for the machine cover.
