1 Introduction User manual SIPLACE SX1/SX2 1.5 Operator levels From software version SC 706.1 SP1 Version 10/2014 26 1.5 Operator levels Certain functions or menus may only be executed or accessed by specially trained pe…

User manual SIPLACE SX1/SX2 1 Introduction

From software version SC 706.1 SP1 Version 10/2014 1.4 Qualification and training of personnel

1.4 Qualification and training of personnel

Personnel used for operation, preventive maintenance, inspection and installation must hold the

relevant qualifications for the job. The user must keep tight control over their responsibilities, as-

signment and supervision. Any employee who does not have the relevant training must be trained

and given appropriate instruction. The instruction is to be given by trained and authorized person-

nel.

SMT Academy

The SMT Academy provides technical training courses for your team, covering everything from

basic SIPLACE operator training to advanced follow-up training for your experts. Our courses can

either be held at your company or at one of our SIPLACE training centers worldwide. In addition

to our range of standard training programs, we can also offer customized courses to meet your

individual requirements.

SIPLACE training courses are always on a modular basis. This means that you can either book a

standard course or compile your own training program with the individual topics required for your

production environment.

Training courses for SIPLACE SX

Special operator, maintenance and technical (system configuration and repairs) training courses

are available for the SIPLACE SX.

Standard courses for SIPLACE SX

– SIPLACE operator training

– SIPLACE minor and major maintenance train-

ing for SX

– SIPLACE technical training for SX

Advanced and customized courses for

SIPLACE SX

– SIPLACE SX advanced training modules

– SIPLACE SX upgrade training modules

Other training courses

– SIPLACE programmer training for SIPLACE

Pro

– SIPLACE Vision Training

– SIPLACE feeder care training

PLEASE NOTE

Operation of system only by qualified personnel

 Only staff with the relevant qualifications may start up, operate or otherwise work on

the machine.

The qualification must be proven by means of training courses or instruction for the per-

sonnel.

1 Introduction User manual SIPLACE SX1/SX2

1.5 Operator levels From software version SC 706.1 SP1 Version 10/2014

1.5 Operator levels

Certain functions or menus may only be executed or accessed by specially trained personnel. A

differentiation is made between the following operator levels:

– Production

– Advanced production

– Service (customer)

– Service (SIPLACE)

The operator levels "Advanced production" and "Service (customer)" can be password protected.

The operator level "Service (SIPLACE)" is already password protected.

Production 1

This operator level includes those people who have been trained to operate the machine. These

people are authorized to use any functions associated with operating the machine and may call

up any menus needed to use the machine.

Advanced production 1

People with this operator level have completed special training and are authorized to perform

setup tasks e.g. creating setup configurations or determining Vision parameters etc.

Service (customer) 1

People with this operator level are specially trained technicians at the customer end, who can, for

example, define machine option settings.

Service (SIPLACE) 1

People with this operator level are trained to perform service work, such as the conversion and

retrofitting of machines.

User manual SIPLACE SX1/SX2 1 Introduction

From software version SC 706.1 SP1 Version 10/2014 1.6 Important notes on the user manual

1.6 Important notes on the user manual

1.6.1 Contents and filing of the user manual

This user manual contains basic information that must be observed when setting up, operating

and maintaining the machine. The service engineers, qualified staff, operators and users plus sys-

tem owner must therefore read it before commencing installation and commissioning. The instruc-

tions must be kept permanently accessible where the machine is used.

In addition, the user must ensure that the employees have fully understood the contents of the

user manual.

1.6.2 Danger notes

1.6.3 Manufacturer's/supplier's liability

We hereby confirm that the contents of this user manual are of a descriptive and explanatory na-

ture only and do not contain any contractual conditions or guaranties. The liability and obligations

assumed by ASM Assembly Systems GmbH&Co.KG can be found exclusively in the relevant

contract agreement concerning the supply of the machine described in this manual. This applies

in particular to all statements regarding performance or service life and the agreed liability for

faults or defects. The provisions of the contract regarding the liability for faults or defect are neither

extended nor restricted by any statements in this user manual.

WARNING

Read the user manual!

 Tasks may only be performed by qualified staff who have completed the relevant

training.

 Only perform tasks on the machine if you have precise knowledge of the relevant sec-

tion in the user manual.

 Observe all warnings, caution notes and hazard notes.

 Please also read chapter 2 of this user manual through carefully.
