User manual SIPLACE SX1/SX2 1 Introduction
From software version SC 706.1 SP1 Version 10/2014 1.6 Important notes on the user manual
27
1.6 Important notes on the user manual
1.6.1 Contents and filing of the user manual
This user manual contains basic information that must be observed when setting up, operating
and maintaining the machine. The service engineers, qualified staff, operators and users plus sys-
tem owner must therefore read it before commencing installation and commissioning. The instruc-
tions must be kept permanently accessible where the machine is used.
In addition, the user must ensure that the employees have fully understood the contents of the
user manual.
1.6.2 Danger notes
1
1.6.3 Manufacturer's/supplier's liability
We hereby confirm that the contents of this user manual are of a descriptive and explanatory na-
ture only and do not contain any contractual conditions or guaranties. The liability and obligations
assumed by ASM Assembly Systems GmbH&Co.KG can be found exclusively in the relevant
contract agreement concerning the supply of the machine described in this manual. This applies
in particular to all statements regarding performance or service life and the agreed liability for
faults or defects. The provisions of the contract regarding the liability for faults or defect are neither
extended nor restricted by any statements in this user manual.
WARNING
Read the user manual!
Tasks may only be performed by qualified staff who have completed the relevant
training.
Only perform tasks on the machine if you have precise knowledge of the relevant sec-
tion in the user manual.
Observe all warnings, caution notes and hazard notes.
Please also read chapter 2 of this user manual through carefully.
1 Introduction User manual SIPLACE SX1/SX2
1.6 Important notes on the user manual From software version SC 706.1 SP1 Version 10/2014
28
1.6.4 Revision table
1
1.6.5 Further information about and contents of the documentation package
1.6.5.1 How to get information
If you have any further questions concerning this manual or if you would like additional information
on a particular topic, please get in touch with your local SIPLACE dealer or contact us directly at:
ASM Assembly Systems GmbH&Co.KG
Rupert-Mayer-Str. 44
81379 Munich 1
Edition Amendments
04/2012 EN First edition with SC.706.xx
01/2013 EN Station software SC.706.1 SP1
Formal amendments
Changes to overall views (operating panel)
04/2014 EN Station software from SC.706.1 SP1
SIPLACE JTF-S/JTF-M
SIPLACE Very High Force TwinStar (VHF TH)
SIPLACE 12 segment Collect&Place head (C&P12)
03015 placement
Formal amendments
10/2014 EN New sales numbers for machine types
SIPLACE SmartFeeder 8 mm X
Universal nozzle changer for SIPLACE CPx
User manual SIPLACE SX1/SX2 1 Introduction
From software version SC 706.1 SP1 Version 10/2014 1.6 Important notes on the user manual
29
1.6.5.2 SIPLACE on the World Wide Web (WWW)
We also have our own site on the Internet. Why not log onto our SIPLACE home page at http://
www.siplace.com.
1
All the menus and other information are available in two languages: You can choose between the
German and English versions.
The various headings contain information on
– Our products
– Services
– Contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– Technical documentation
– Technical information
– Spare parts catalogs etc.
Registering for access to the User Group is easy:
Click on ’Register now’.
Complete the registration form and just send it off.
You will then quickly receive access authorization with USER ID and a password.
