2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This user manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
2
2
2
2
DANGER
Definition
Danger, as used in this user manual, means that death, severe injury or considerable
damage to equipment will occur if the danger instructions are not followed.
WARNING
Definition
Warning, as used in this user manual, means that death, severe injury or considerable
damage to equipment may occur if the warning instructions are not followed.
CAUTION
Definition
Caution, as used in this user manual, means that slight injury or damage to equipment
may occur if the caution instructions are not followed.
PLEASE NOTE
Definition
A note, as used in this user manual, provides information on the product or indicates a part
of the user manual that requires particular attention.
2 Operational safety User manual SIPLACE SX1/SX2
2.1 Safety instructions From software version SC 706.1 SP1 Version 10/2014
34
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and preventive maintenance of placement machines and add-on devices and are suit-
ably qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– Have received first aid training.
2.1.3 Important notes on operational safety
The following points MUST be observed in order to maintain operational safety:
2.1.3.1 General
The operational safety of SMD placement machines can be guaranteed only if the system is
used as prescribed and in accordance with the instructions in the user/preventive mainte-
nance manuals.
Always follow any safety regulations specific to your country.
Make sure that the warning labels are always clearly identifiable and always easily readable.
Replace any damaged warning or notice labels. Replace any labels that are missing.
The machine key for releasing the covers on the machine must be kept in a safe place where
it is only accessible to qualified personnel.
2
2
If it is necessary to work on the machine and you do not have adequately trained personnel
within your operation, always call in a ASM Assembly Systems GmbH&Co.KG service engi-
neer! ASM Assembly Systems GmbH&Co.KG will not accept liability for any damage or con-
sequential damage that is the result of unauthorized/incorrect work.
If particularly hazardous situations are identified while the machine is in use, the machine
owner must immediately notify the manufacturer in writing so that appropriate action can be
taken to reduce the potential danger.
PLEASE NOTE
Owner's responsibility
The machine owner, and only the machine owner, is responsible for the safekeeping of
the machine key and for ensuring that it is handed over to authorized persons.
