13. STACKER COMPONENTS
6
6
2
2
3
3
4
5
4
4
5
4
4
1
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-24580 CASSETTE ASM 1
2 401-24265 STOPPER (2)
3 401-24266 SHAFT (4)
4 401-24267 LOW HEAD CAP SCREW (8)
5 - BOLT M4X15 (4)
6
#01
401-24264 SHELF BOARD (1)
- -
14. ACCESSORIE COMPONENTS
1
2
3
4
6
5
7
8
