4.Commands SYS-CP842-1.1E
180 CP-842E / CP-842ME System Reference
Set Ignore After Handy Terminal
Command Path: [Maintenance] - [Configuration] - [Handy Terminal] - [Set Ignore
After]
Press to display the keyboard at which the Ignore after comment can be set. Any
characters that appear after the selected comment are ignored by the Handy Termi-
nal.
Revision history:
Set Ignore Between Handy Terminal
Command Path: [Maintenance] - [Configuration] - [Handy Terminal] - [Set Ignore
Between]
Press to display the keyboard at which the Ignore between comment can be set. Any
characters that are enclosed by the selected comment are ignored by the Handy Termi-
nal.
Revision history:
Signal Tower Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Signal Tower]
Press to access the screen at which the signal tower settings can be specified.
Revision history:
Standard I/O check
Command Path: [Maintenance] - [I/O check] - [Standard]
Press to access the screen at which a standard I/O check can be performed.
Revision history:
Start Sequence Production
Command Path: [Production] - [Start Sequence]
Press to display the Numeric Keypad and input the starting sequence.
Revision history:
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 181
Statistical Nozzle Skip Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Statistical Nozzle Skip]
Press to access the Statistical Nozzle Skip Settings screen.
Revision history:
Status Reset Options
Command Path: [Maintenance] - [Options] - [Status Reset]
Press to reset all machine data except calibration and program related data.
Revision history:
Step Production
Command Path: [Production] - [Step]
Press to set the operation mode to Step.
Revision history:
Stop Recovery
Command Path: [Recovery] - [Stop]
Press to set the recovery action to Stop.
Revision history:
System Maintenance
Command Path: [Maintenance] - [System]
Press to access the screen at which system related commands (Date & Time, Network)
can be selected.
Revision history:
System Backup Data Manager
Command Path: [Maintenance] - [Data Manager] - [System Backup]
Press to access the screen at which the system settings can be backed up.
Revision history:
4.Commands SYS-CP842-1.1E
182 CP-842E / CP-842ME System Reference
Tolerance Trace Settings
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Tolerance]
Press for a graphical display of the tolerance information.
Revision history:
Trace Settings Image Buffer
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings]
Press to access the screen at which trace-related settings can be specified.
Revision history:
Travel Limits Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Travel Limits]
Press to access the screen at which machine axes maximum and minimum travel lim-
its can be set in calibration data.
Revision history:
Unclamp Panel Loader
Command Path: [Panel Loader] - [Unclamp]
Press to release the main conveyor panel clamp.
Press the START button to execute the operation.
Revision history:
Unload Panel Loader
Command Path: [Panel Loader] - [Unload]
Press to unload the panel(s) currently on the main conveyor.
Press the START button to execute the operation.
Revision history:
