15 WF2 CA4 V2 Check the nozzle seating of CPP /M and C&P20 A/P/M2 2 min 1 / 1 C A U T I O N ! R e f e r t o s a f e t y i n s t r u c t i o n s i n u s e r m a n u a l b e f o r e c o m m e n c i n g M a i n t e n …
www.asm-smt.com
15 WF2 CA4 V2 Check the nozzle seating of CPP /M and C&P20 A/P/M2 2 min 1 / 1
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Transport Empty
NOTICE! ESD guidelines are to be followed Tool: Wear Part: Consumables:
www.asm-smt.com
1 Click on "Pick up nozzles". 2 Click on "Check nozzle seating". 3 Check if the result is OK (green hook).
4 If the result is NOT OK (red cross) contact
service.
