1 - 12
www.e-by-siplace.com
Standard Nozzles in the 7xx/9xx/30xx Series
3003 (ceramic)
L = 16.000 mm
Tip: 0.900 x 0.500 mm (LxW)
Item no. 03079891
3004 (ceramic)
L = 15.000 mm
Tip: 1.700 x 1.200 mm (LxW)
Item no. 00322602
3005 (ceramic)
L = 16.500 mm
Tip: 0.400 x 0.200 mm (LxW)
Item no. 03057320
3006 (ceramic)
L = 16.500 mm
Tip: 0.440 x 0.350 mm (LxW)
Item no. 00345031
3007 (ceramic)
L = 16.000 mm
Tip: 1.400 x 0.660 mm (LxW)
Item no. 03054846
1 - 13
www.e-by-siplace.com
Standard Nozzles in the 7xx/9xx/30xx Series
3020 (TPU)
L = 12.500 mm
Tip: Ø 7.000 mm
Item no. 00325972
3021 (TPU)
L = 9.000 mm
Tip: Ø 7.000 mm
Item no. 00325970
3056 (TPU)
L = 14.500 mm
Tip: Ø 7.000 mm
Item no. 00330538
3038 (TPU)
L = 11.000 mm
Tip: Ø 4.000 mm
Item no. 00322592
3039 (TPU)
L = 11.000 mm
Tip: Ø 5.000 mm
Item no. 00322593
1 - 14
www.e-by-siplace.com
Standard Nozzles in the 7xx/9xx/30xx Series
3032 (TPU)
L = 14.300 mm, r
tip
= 0.900 mm
Tip: 2.100 x 1.540 mm (LxW)
Item no. 00346522
3034 (TPU)
L = 14.300 mm, r
tip
= 1.000 mm
Tip: 2.900 x 1.650 mm (LxW)
Item no. 00327810
3036 (TPU)
L = 14.300 mm, r
tip
= 0.900 mm
Tip: 1.700 x 1.100 mm (LxW)
Item no. 00352353
3042 (ceramic)
L = 15.000 mm, r
tip
= 0.750 mm
Tip: 1.760 x 1.200 mm (LxW)
Item no. 03094459
3044 (ceramic)
L = 15.000 mm, r
tip
= 1.000 mm
Tip: 1.725 x 1.200 mm (LxW)
Item no. 03094461
3046 (ceramic)
L = 15.300 mm, r
tip
= 0.750 mm
Tip: 1.540 x 1.100 mm (LxW)
Item no. 03094458
