TANTAL 7.3x4.3 D [7.3x4.3x3.0] 303 TANTAL 8.0x6.4 [8.0x6.4x3.5] 310 TANTAL 10.5x8.0 [10.5x8.0x3.5] 311 2 - 9 www.e-by-siplace.com
2 pin components CP6 CP12 CP14 PP / TH
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
TANTAL
3.2x1.6 A
[3.2x1.6x1.8]
300
TANTAL
3.4x2.8 B
[3.5x2.8x2.1]
301
TANTAL
5.8x3.2 C
[6.0x3.2x2.8]
302
2 - 8
www.e-by-siplace.com
TANTAL
7.3x4.3 D
[7.3x4.3x3.0]
303
TANTAL
8.0x6.4
[8.0x6.4x3.5]
310
TANTAL
10.5x8.0
[10.5x8.0x3.5]
311
2 - 9
www.e-by-siplace.com
2 pin components CP6 CP12 CP14 PP / TH
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
ECV A
Ø3.0 H5.7
[3.6x3.3x5.7]
340
ECV B
Ø4.0 H5.7
[4.6x4.3x5.7]
341
ECV C
Ø5.0 H5.7
[5.9x5.3x5.7]
342
ECV D
Ø6.3 H5.7
[7.0x6.6x5.7]
343
2 - 10
www.e-by-siplace.com
