SO components CP6 CP12 CP14 PP / TH Component shape [LxWxH (mm)] CS file Nozzle types SSOP 38 [12.6x7.8x1.8] 661 SSOP 44 [17.9x10.3x2.515] 663 SSOP 48 [15.88x10.31x2.59] 664 SSOP 56 [18.4x10.35x2.6] 665 4 - 12 www.e-by-s…
SSOP 18 / SSOP 20
[7.2x7.8x1.8]
653 /
654
SSOP 22 / SSOP 24
[9.2x7.8x1.8]
655 /
656
SSOP 28 / SSOP 30
[10.2x7.8x1.8]
657 /
658
SSOP 34
[18.1x10.25x2.6]
659
SSOP 36
[15.6x10.35x2.6]
660
4 - 11
www.e-by-siplace.com
SO components CP6 CP12 CP14 PP / TH
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
SSOP 38
[12.6x7.8x1.8]
661
SSOP 44
[17.9x10.3x2.515]
663
SSOP 48
[15.88x10.31x2.59]
664
SSOP 56
[18.4x10.35x2.6]
665
4 - 12
www.e-by-siplace.com
SSOP 64
[26.3x14.25x2.1]
666
4 - 13
