- - 18. X-YCO MPONENTS(2) 1 0 1 0 1 4 1 3 1 1 1 2 6 1 1 1 3 1 2 1 4 1 5 2 3 1 5 2 3 1 6 1 6 2 5 8 7 1 2 4 3 2 4 1 8 1 9 2 0 2 1 2 2 1 4 1 7 1 7 1 4 2 2 2 1 2 0 1 9 1 8 5 5 9

100%1 / 148
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-37048 X_AXIS_FRAME_ASM 1
2 401-13992 XAXISFRAMEASM 1
3 401-36745 X_AXIS_FRAME (1)
4 400-71325 XLMGUIDEL (2)
5 SM-6041602-TN SCREWM4X16 (34)
6 PH-0300082-C0 PIN 2
7 400-49671 COVERCUSHION 2
8 401-37095 XPLUSLMTSENSORASSY 1
9 SM-6030602-TN SCREWM3X6 2
10 401-37096 XMINUSLMTSENSORASSY 1
11 SM-6030602-TN SCREWM3X6 2
12 SM-4030601-SC SCREWM3X6 2
13 401-06022 XFRAMEENDR 1
14 401-36754 X_STOPPER_BR 1
15 SL-6062092-TN SCREWM6L=20 4
16 401-06020 XFRAMEENDL 1
17 SL-6062092-TN SCREWM6L=20 4
18 401-10215 YSENSORDOG 1
19 SL-6040892-TN SCREWM4L=8 2
20 SL-4030891-SC SCREWM3L=8 1
21 SL-6052592-TN SCREWM5L=25 2
22 SM-6061602-TN SCREWM6L=16 4
23 SM-4040601-SC SCREWM4X0.7L=6 14
24 HX-0029400-00 FIXEDBASE 14
25 SL-6052592-TN SCREWM5L=25 16
26 SL-6040892-TN SCREWM4L=8 4
27 401-10222 X_STOPPER 1
28 400-98047 XBALLSCREWXL 1
29 401-13985 XMOTORFRAMEASM 1
30 SL-6051692-TN SCREWM5L=16 4
31 401-29653 XAXISMOTOR 1
32 SL-6062042-TN SCREWM6L=20 4
33 400-93855 FIXEDSUPPORTUNIT 1
34 SM-6052002-TN SCREW 4
35 SM-6044002-TN SCREWM4X0.7L=40 2
36 401-47719 COUPLING_X 1
37 400-93863 XBALLSCREWSUPPORT 1
38 400-93864 O_RING_X 1
39 401-10217 XBSFRAME 1
40 SM-4030601-SC SCREWM3X0.5L=6 3
41 HX-0034400-00 FIXEDBASE 2
42 SL-6053092-TN SCREWM5L=30 2
43 SL-6042592-TN SCREWM4L=25 2
44 SL-6044092-TN SCREWM4L=40 2
45 SM-4040601-SC SCREWM4X0.7L=6 9
46 HX-0029400-00 FIXEDBASE 7
47 400-49671 COVERCUSHION 3
48 CM-3003000-03 HIGHTEMPARATURECAUTIONLABEL2(31.5) 1
- -
18.X-YCOMPONENTS(2)
1 0
1 0
1 4
1 3 1 1
1 2
6
1 1
1 3
1 2
1 4
1 5 2 3
1 5 2 3
1 6
1 6
2 5
8
7
1
2 4
3
2
4
1 8
1 9
2 0
2 1
2 2
1 4
1 7
1 7
1 4
2 2
2 1
2 0
1 9
1 8
5
5
9
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-37097 Y_SENSOR_BR_F_ASM 1
2 401-36751 Y_SENSOR_BR (1)
3 401-37317 YPOSLIMITSENSORASM (1)
4 401-37319 YNEARSENSORASM (1)
5 SM-4860801-SC SCREWM2.6L=8 (2)
6 401-37098 Y_SENSOR_BR_R_ASM 1
7 401-36751 Y_SENSOR_BR (1)
8 401-37318 YNEGLIMITSENSORASM (1)
9 SM-4860801-SC SCREWM2.6L=8 (1)
10 401-13989 YSTOPPERASM 2
11 400-00708 YSTOPPER (1)
12 400-49671 COVERCUSHION (2)
13 SM-4030601-SC SCREWM3X0.5L=6 (2)
14 SM-6126002-TN SCREWM12L=60 8
15 401-06039 YLMGUIDEL 2
16 SM-6051602-TN SCREW 48
17 401-37049 Y_STOPPER_ASM_A 2
18 400-00708 YSTOPPER (1)
19 401-36747 Y_STOPPER_BR (1)
20 SL-6030892-TN SCREWM3L=8 (2)
21 400-49671 COVERCUSHION (2)
22 SM-4030601-SC SCREWM3X0.5L=6 (2)
23 400-98046 Y_LM_GUIDE_XL 2
24 SL-6040892-TN SCREWM4L=8 2
25 SL-6040892-TN SCREWM4L=8 2
