NP-153E P ARTS LIST ver03 3 - 1 3 . ヘッド 2 ( インデックス) ( D D P H ) 3 . H e a d 2 ( I n d e x ) ( D D P H ) 3 . ヘッド 2 ( インデックス) ( D D P H ) 3 . H e a d 2 ( I n d e x ) ( D D P H ) 2 0 8 1 7 6 1 6 5 1 7 5 1 6 1 1 7 5 1 6 1 1 …

100%1 / 104
2.ヘッド １(ノズル)(DDPH)
2.Head 1(Nozzles)(DDPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 ADFPH8020 33 NOZZLE ﾉｽﾞﾙ
2 DFPH2090 33 COLLAR ｶﾗｰ t=1.0 注1.Note.1
3 DFPH2050 33 SPRING ｽﾌﾟﾘﾝｸﾞ
4 DFPH2070 33 COLLAR ｶﾗｰ
5 DFPH2010 33 SHAFT ｼｬﾌﾄ
6 DFPH2020 33 WHIRL STOP 回止め
7 DFPH2040 33 GEAR, BEVEL ｷﾞﾔ ﾍﾞﾍﾞﾙ
8 DFPH2060 33 HOLDER ﾎﾙﾀﾞ
9 DFPH2030 33 BOLT ﾎﾞﾙﾄ
10 DFPH2080 33 NUT ﾅｯﾄ
11 ADFPH8010 33 SLEEVE ｽﾘｰﾌﾞ
13 H5134A 66 O RING Oﾘﾝｸﾞ S 12
14 H4195C 66
BEARING
ﾍﾞｱﾘﾝｸﾞ 6800ZZP5
15 H4446A 33
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1150ZZ
16 DFPH2290 32 SPRING ｽﾌﾟﾘﾝｸﾞ
17 DFPH2270 32 SPRING ｽﾌﾟﾘﾝｸﾞ
19 DFPH2281 32 RETAINER 押え
20 DFPH2240 32 SHAFT ｼｬﾌﾄ
21 DFPH2300 32 STOPPER ｽﾄｯﾊﾟ
22 DFPH2310 32 SPRING ｽﾌﾟﾘﾝｸﾞ
23 H3026H 32 FILTER ﾌｨﾙﾀ 4.7X0.1
24 DFPH2260 32 SPRING ｽﾌﾟﾘﾝｸﾞ
25 DFPH2250 32 STOPPER ｽﾄｯﾊﾟ
注1.仕様選択部品 DFPH2100(t=0.3),DFPH2110(t=0.4),DFPH2120(t=0.5),DFPH2130(t=0.6),DFPH2140(t=0.7),
DFPH2150(t=0.8),DFPH2160(t=0.9),DFPH2170(t=1.1),DFPH2180(t=1.2),DFPH2190(t=1.3),DFPH2200(t=1.4),DFPH2210(t=1.5)
Note.1 : (Specified part selection)DFPH2100(t=0.3),DFPH2110(t=0.4),DFPH2120(t=0.5),DFPH2130(t=0.6),DFPH2140(t=0.7),
DFPH2150(t=0.8),DFPH2160(t=0.9),DFPH2170(t=1.1),DFPH2180(t=1.2),DFPH2190(t=1.3),DFPH2200(t=1.4),DFPH2210(t=1.5)
NP-153E PARTS LIST ver03
2 - 2
2.ヘッド 1(ノズル)(DDPH)
2.Head 1(Nozzle)(DDPH)
NP-153E PARTS LIST ver03
3 - 1
3.ヘッド 2(インデックス)(DDPH)
3.Head 2(Index)(DDPH)
3.ヘッド 2(インデックス)(DDPH)
3.Head 2(Index)(DDPH)
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
46
58
134
143
144
69
40
43
45
69
53
135
70
41
42
69
53
44
100
127
128
110
111
111
124
125
124
110
111
127
128
111
126
B
A
C
C
B
A
Side 2
70
56
70
56
56
70
56
70
71
107
26
98
71
62
61
71
1
67
73
75
56
70
74
141
139
56
70
74
142
140
67
79
83
9
25
2
35
11
70
56
58
12
37
5
78
57
38
102
6
24
99
69
53
32
32
15
Side 2
Side 1
39
x6.5
115
115
131
72
120
112
119
118
109
70
129
114
122
123
117
132
72
137
136
72
137
121
132
145
146
72
138
70
129
130
71
113
71
61
57
70
34
106
108
108
108
108
105
105
105
105
104
86
78
58
87
78
56
57
70
74
93
57
70
74
94
57
70
95
78
58
88
78
56
91
57
70
74
92
57
74
70
94
95
78
58
88
78
56
78
58
87
97
31
30
23
55
77
103
58
70
74
56
70
74
78
56
52
47
90
33
81
52
48
91
84
57
70
28
71
63
29
60
78
4
29
27
7
74
70
58
56
74
140
70
86
52
48
33
81
89
52
47
Side 2
3.ヘッド ２(インデックス)(DDPH)
3.Head 2(Index)(DDPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
1 DFPH0181 1 BKT, MOTOR BKT ﾓｰﾀ
2 DFPH0191 1 BKT, MOTOR BKT ﾓｰﾀ
4 DFPH0430 2 BKT BKT
5 DFPH0410 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
6 DFPH0560 2 COLLAR ｶﾗｰ
7 DFPH0200 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
9 DFPH0220 2 PIN, LOCATING ﾋﾟﾝ 位置決め
11 DFPH0230 2 PLATE ﾌﾟﾚｰﾄ
12 DFPH0241 2 BKT, MOTOR BKT ﾓｰﾀ
15 DFPH0250 2 BOLT, CLAMP ﾎﾞﾙﾄ ｸﾗﾝﾌﾟ
23 DFPH0260 2 HOLDER ﾎﾙﾀﾞ
24 N1023A 2
NUT, LOCK
ﾅｯﾄ ﾛｯｸ ZMV20
25 H42697 2 BEARING ﾍﾞｱﾘﾝｸﾞ 7912A5DB
26 H42694 2 BEARING ﾍﾞｱﾘﾝｸﾞ 7905A5 P5
27 H4206H 2
BEARING
ﾍﾞｱﾘﾝｸﾞ 60/22ZZ
28 A3034A 2
PLUG
埋栓             
PT1/8
29 H1167D 4 PACKING ﾊﾟｯｷﾝ MY-20
30 A5170Y 2 O RING Oﾘﾝｸﾞ S90
31 A51701 2 O RING Oﾘﾝｸﾞ S95
32 R20598 4 RING, LOCKING ﾘﾝｸﾞ 締結 PL012X015E
33 S4032S 2 SENSOR ｾﾝｻ UM-T50SV
34 DFPH0070 2 MOTOR ﾓｰﾀ
35 DFPH0080 2 MOTOR ﾓｰﾀ
37 DFPH0360 2 PULLEY, TIMING ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ
38 H4521W 3 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 450-5GT-20
39 DFPH0380 2 GEAR, BEVEL ｷﾞﾔ ﾍﾞﾍﾞﾙ
40 DFPH0040 2 DOG ﾄﾞｯｸﾞ
41 DFPH0050 1 BKT BKT
42 DFPH0060 1 BKT, SENSOR BKT ｾﾝｻ
43 CPPH2810 2 HOLDER ﾎﾙﾀﾞ
44 S40441 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX770
45 S40445 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX771
46 H4269W 2 BEARING, ANGULAR ﾍﾞｱﾘﾝｸﾞ ｱﾝｷﾞｭﾗ 7004CP4
47 S40546 1 SENSOR, FIBER ｾﾝｻ ﾌｧｲﾊﾞ HPF-S097
48 S40547 1 SENSOR, FIBER ｾﾝｻ ﾌｧｲﾊﾞ HPF-S098
52 H5271A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M2.6X8L
53 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X8L
NP-153E PARTS LIST ver03
3 - 2
3.ヘッド 2(インデックス)(DDPH)
3.Head 2(Index)(DDPH)
