9.Z軸(サイド１)(DDPZ) 9.Z axis(Side 1)(DDPZ) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 68 DFPZ0230 1 BKT BKT 69 DFPZ0200 1 LEVER ﾚﾊﾞｰ 70 DFPZ0270 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ 71 DFPZ0…
9.Z軸(サイド１)(DDPZ)
9.Z axis(Side 1)(DDPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
3 DFPZ0150 1 PIN, PIVOT ﾋﾟﾝ 支点
4 W1092X 1 WASHER ﾜｯｼｬ WSSM6-4-1
14 DFPZ0380 1 BKT, SOL BKT SOL
15 DFPZ0160 1 WASHER ﾜｯｼｬ
28 H4241D 2 BEARING ﾍﾞｱﾘﾝｸﾞ RF-1140ZZ
29 K1090A 2 CAM FOLLOWER ｶﾑﾌｫﾛｱ CFS04
31 . 2 JOINT ｼﾞｮｲﾝﾄ TSH4-M3M
32 Y3020L 2 UNION ﾕﾆｵﾝ UB4M
34 SAM6630 1 MOTOR ﾓｰﾀ ULSE-02-FJ11
35 H5265A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X6L
36 H5268H
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X12L
38 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
39 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L
40 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
41 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12L
42 H5282A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X30L
44 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
45 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
47 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
48 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
49 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
50 W1042A
WASHER, FLAT
ﾜｯｼｬ 平
4W-3
51 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
52 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
54 DFPZ0290 1 BKT, SENSOR BKT ｾﾝｻ
55 DFPZ0170 1 SPRING ｽﾌﾟﾘﾝｸﾞ
56 DFPZ0090 1 JOINT ｼﾞｮｲﾝﾄ
58 DFPZ0220 1 BOLT ﾎﾞﾙﾄ
59 DFPZ0180 1 BKT BKT
60 DFPZ0280 1 PUSHER ﾌﾟｯｼｬ
61 DFPZ0010 1 BKT BKT
62 DFPZ0190 1 DOG ﾄﾞｯｸﾞ
63 DFPZ0030 1 PUSHER ﾌﾟｯｼｬ
64 DFPZ0130 1 PLATE ﾌﾟﾚｰﾄ
65 DFPZ0100 1 BKT BKT
66 DFPZ0330 1 BKT BKT
67 DFPZ0050 1 PLATE ﾌﾟﾚｰﾄ
NP-153E PARTS LIST ver03
9 - 2
9.Z軸(サイド 1)(DDPZ)
9.Z axis(Side 1)(DDPZ)
9.Z軸(サイド１)(DDPZ)
9.Z axis(Side 1)(DDPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
68 DFPZ0230 1 BKT BKT
69 DFPZ0200 1 LEVER ﾚﾊﾞｰ
70 DFPZ0270 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
71 DFPZ0070 1 BKT BKT
73 DFPZ0390 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL
74 H3120F 3 PLUG 埋栓 UP4
75 Y3077Z 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L04-M5
76 DFPZ0440 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CSA16X15-361W
77 DFPZ0410 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ KA10X8-967W
78 Y3045F 3 ELBOW ｴﾙﾎﾞ TL4-M3M
79 R2037A 12 RING, INSERT ﾘﾝｸﾞ ｲﾝｻｰﾄ WR0425
80 T2060A 1 TUBE ﾁｭｰﾌﾞ SP-4LBX100M
81 S4045D 1 SENSOR ｾﾝｻ ﾌｫﾄ EE-SX870
82 DFPZ0430 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ KA8X5-923W
83 K5357T
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X8L
84 K5359E
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X8L
85 H5283T
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X45L
86 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
87 N1080A NUT, HEX ﾅｯﾄ 六角 M4 P=0.7
88 W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
89 K5331H CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SSU4-300W
90 DFPZ0250 1 BKT, WIRING BKT 配線
91 DFPZ0120 1 BKT, STOPPER BKT ｽﾄｯﾊﾟ
92 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
93 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
94 DFPZ0210 1 HOLDER ﾎﾙﾀﾞ
95 A1034T 1 ABSORBER, SHOCK ｱﾌﾞｿｰﾊﾞ ｼｮｯｸ KSHA6X5-A
96 S1053F 1 SILENCER ｻｲﾚﾝｻ KM-11
97 S2171A 1 JOINT ｼﾞｮｲﾝﾄ TL6-01
98 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L
99 DFPZ0350 1 PLATE, CLAMPING ﾌﾟﾚｰﾄ ｸﾗﾝﾌﾟ
100 W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5
101 H52966
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X6L
102 DFPZ0370 1 SHEET, RUBBER ｼｰﾄ ｺﾞﾑ
103 DFPZ0310 1 HOLDER, SENSOR ﾎﾙﾀﾞ ｾﾝｻ
104 S4051Z SENSOR, FIBER ｾﾝｻ ﾌｧｲﾊﾞ E32-D24
105 DFPZ0140 1 STOPPER ｽﾄｯﾊﾟ
NP-153E PARTS LIST ver03
9 - 3
9.Z軸(サイド 1)(DDPZ)
9.Z axis(Side 1)(DDPZ)
9.Z軸(サイド１)(DDPZ)
9.Z axis(Side 1)(DDPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
106 DFPZ0360 1 RETAINER, WIRING ｵｻｴ 配線
107 A5265A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X5L
108 H5267A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X8L
109 N1074T
NUT, HEX
ﾅｯﾄ 六角
M2 P=0.4
110 W1020A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M ･
NP-153E PARTS LIST ver03
9 - 4
9.Z軸(サイド 1)(DDPZ)
9.Z axis(Side 1)(DDPZ)
