NP-153E-03 - 第70页

2 0 . 2 . 本体( D D A B )  2 0 . 2 . B o d y ( D D A B ) 2 0 . 2 . 本体( D D A B )  2 0 . 2 . B o d y ( D D A B ) NP-153E P ARTS LIST ver03 2 0 - 3 X 1 6 1 1 1 0 9 8 1 5 3 3 2 9 1 4 3 4 3 2 2 8 3 4 3 2 2 8 B B A A 3 1 2 6 …

100%1 / 104
20.1.本体(DDAB)
20.1.Body(DDAB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DFAB0010 1 BED ﾍﾞｯﾄﾞ
2 DFAB0210 1 LEG 脚
3 DFAB0220 1 LEG 脚
4 DFAB0230 2 COVER 蓋
5 DDWB0010 1 VALVE UNIT ﾊﾞﾙﾌﾞ ﾕﾆｯﾄ
6 A4002H 1 EJECTOR ｴｼﾞｪｸﾀ VDBL10R6-08SA-D-1.0-F
7 K5331Y 4
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SSU6-300W
8 DFWB0090 1 BKT BKT
9 DDWB0040 1 BKT, WIPING BKT 配線
10 DDWB0020 1 BOLT ﾎﾞﾙﾄ
11 DDWB0030 2 BKT BKT
12 DDWB0060 1 BKT, WIPING BKT 配線
14 DDWB0050 1 BKT, WIPING BKT 配線
16 DFWB0150 8 SHEET, RUBBER ｼｰﾄ ｺﾞﾑ
17 DFWB0160 24 WASHER ﾜｯｼｬ
20 H5280A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X20L
21 K5208A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L
22 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X8L
23 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X10L
24 H5296A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X40L
25 H5394A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M12X50
26 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
27 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
28 W1027A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M
29 N1076A
NUT, HEX
ﾅｯﾄ 六角         
M3 P=0.5
30 W1048A WASHER, FLAT ﾜｯｼｬ 平 4W-12 ･
NP-153E PARTS LIST ver03
20 - 2
20.1.本体(DDAB)
20.1. Body(DDAB)
20.2.本体(DDAB)
20.2.Body(DDAB)
20.2.本体(DDAB)
20.2.Body(DDAB)
NP-153E PARTS LIST ver03
20 - 3
X16
11
10
9
8
15
33
29
14
34
32
28
34
32
28
B
B
A
A
31
26
1
22
20
35
33
30
37
33
31
26
22
37
33
21
35
33
30
5
38
28
32
34
17
27
7
27
7
4
2
3
16
32
28
12
27
6
27
6
27
36
18
19
25
6
27
27
6
13
27
27
7
7
27
C
C
20.2.本体(DDAB)
20.2.Body(DDAB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DFAB0010 1 BED ﾍﾞｯﾄﾞ
2 WAB5540 18 BOLT, LEVELING ﾎﾞﾙﾄ ﾚﾍﾞﾘﾝｸﾞ
3 DFAB0020 18 NUT ﾅｯﾄ
4 BB42331 18 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ
5 CGAB0430 6 BKT BKT Red color
6 DFAB0190 4 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
7 DFAB0200 4 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
8 DDAB0020 1 RETAINER 押え
9 DDAB0030 1 RETAINER 押え
10 DFAB0090 1 RETAINER 押え
11 DFAB0180 1 RETAINER 押え
12 DDAB0040 1 COVER, LOWER ｶﾊﾞｰ 下
13 DDAB0050 1 COVER, LOWER ｶﾊﾞｰ 下
14 DDAB0060 1 DUCT, WIRING ﾀﾞｸﾄ 配線
15 DDAB0070 1 BKT BKT
16 DFAB0030 1 BKT, STOPPER BKT ｽﾄｯﾊﾟ
17 DDAB0080 1 DUCT, WIRING ﾀﾞｸﾄ 配線
18 DFAB0120 3 BKT BKT
19 DFAB0130 3 BKT BKT
20 DFAB0140 1 PLATE ﾌﾟﾚｰﾄ
21 DFAB0150 1 PLATE ﾌﾟﾚｰﾄ
22 DFAB0160 4 DAMPER ﾀﾞﾝﾊﾟ
25 K5209A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X8L
26 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X12L
27 K5215A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X10L
28 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X12L
29 H5340A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M8X15L
30 H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M8X25L
31 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
32 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
33 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
34 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
35 W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8
36 N1080A
NUT, HEX
ﾅｯﾄ 六角         
M4 P=0.7
37 N1090A NUT, HEX ﾅｯﾄ 六角 M8 P=1.25
38 H5122A 4 BOLT, EYE ﾎﾞﾙﾄ ｱｲ M16
NP-153E PARTS LIST ver03
20 - 4
20.2.本体(DDAB)
20.2.Body(DDAB)
