26.ｴｱｰ配管図 26.Pneumatic circuit diagram 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 38 S2101T 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQ2A25-20DCM-A73 39 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ TBDA16X20…
26.ｴｱｰ配管図
26.Pneumatic circuit diagram
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 K1159A 1
COUPLER
ｶﾌﾟﾗ 400PM
2 H1059E 1
VALVE, STOP
ﾊﾞﾙﾌﾞ ｽﾄｯﾌﾟ RP-LL 1/2B
4 H3028Y 1 FILTER REGULATOR ﾌｨﾙﾀﾚｷﾞｭﾚｰﾀ AC4040-04C-R-X1110
5 H3032C 1 FILTER REGULATOR ﾌｨﾙﾀﾚｷﾞｭﾚｰﾀ AW4000-04C-R
6 S4016W 1 SEPARATOR, MIST ｾﾊﾟﾚｰﾀ ﾐｽﾄ AFM4000-04C-R
7 A1031A 1
PRESSURE GAUGE
圧力計
G46-10-02
8 S3157Z 1
SW, PRESSURE
SW ﾌﾟﾚｯｼｬ IS3010-02L5
9 T20619 1 HOSE, AIR ﾎｰｽ ｴｱｰ IN-241-800-20-X
10 DFWB0040 1 MANIFOLD, AIR ﾏﾆﾎｰﾙﾄﾞ ｴｱｰ
11 DDWB0010 1 VALVE UNIT ﾊﾞﾙﾌﾞ ﾕﾆｯﾄ
12 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F10T2-A1-PL3 DC24V
13 3 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F10T2-FM-PL3-115W DC24V
14 3 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SC4-M5MB
15 3 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SS4-M5MB
16 K5331Y 5 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SSU6-300W
17 S21253 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CQ2D50-40DCM
18 H1050K 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ C250-01-32W
19 H1062W 2 VALVE, MECHANICAL ﾊﾞﾙﾌﾞ ﾒｶﾆｶﾙ 80-VM121-01-01
20 S2126L 3 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CXSM10-K6869-35
21 A4002H 1 EJECTOR ｴｼﾞｪｸﾀ VDBL10R6-08SA-D-1.0-F
22 H5447E 1 PUMP, VACUUM ﾎﾟﾝﾌﾟ ﾊﾞｷｭｰﾑ KHA400-DV-7551-G1
24 S4033W 1 SENSOR, PRESSURE ｾﾝｻ 圧力 AP-31A
25 DFPZ0390 2 VALVE UNIT ﾊﾞﾙﾌﾞ ﾕﾆｯﾄ
26 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL A040E1-2-PSL-IL DC24V
27 4 VALVE, SOL ﾊﾞﾙﾌﾞ SOL A040-4E1-PSL-1L DC24V
28 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL A040E1-PSL-1L DC24V
29 90745CPPZ5060 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
30 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ ﾟ8Xﾟ10(KA10X8-966W)
31 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ ﾟ8Xﾟ10(KA10X8-96７W)
32 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CSA16X15(-B)-361W
33 K5331H 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SSU4-300W
34 DDUZ0040 2 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ
35 DFPM0150 2 VALVE UNIT ﾊﾞﾙﾌﾞ ﾕﾆｯﾄ
36 4 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F10T1-FM-PL3 DC24V
37 8 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SC6-M5MB
NP-153E PARTS LIST ver03
26 - 2
26.ｴｱｰ配管図
26.Pneumatic circuit diagram
26.ｴｱｰ配管図
26.Pneumatic circuit diagram
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
38 S2101T 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQ2A25-20DCM-A73
39 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ TBDA16X20-ZE102A2-52W
41 H10282 2 VALVE, PRESSURE REDUCING ﾊﾞﾙﾌﾞ 減圧 AR2000-01BG-R
42 H1138Z 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL 80-VK332-5G-M5-F
47 H50072 1 HOSE, AIR ﾎｰｽ ｴｱｰ UBS0640-20W
48 H50078 1 HOSE, AIR ﾎｰｽ ｴｱｰ UBS1611-20W
49 DFWB0170 2 TERMINAL, PIPING ﾀｰﾐﾅﾙ 配管
50 DFWB0180 2 TERMINAL, PIPING ﾀｰﾐﾅﾙ 配管
51 H1200A 1
PIPE, DOUBLE ENDED
ﾊﾟｲﾌﾟ 両口
1/2X35
52 A4085F 1 ELBOW, MALE AND FEMALE ｴﾙﾎﾞ ｵｽﾒｽ GF-SL-1/2
53 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQVS06-02S
54 Y3041A 1
UNION
ﾕﾆｵﾝ KQT06-00
55 Y3036A 1
UNION
ﾕﾆｵﾝ KQE06-02
56 Y3058L 1
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQH16-04S
57 Y30203 3 UNION ﾕﾆｵﾝ UT6M
58 Y3045C 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ TLL6-01M
59 Y3045M 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ SL16-04
60 S2174A 4 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL8-02
61 S2172A 2 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-02
62 S2175A 3
JOINT, ONE-TOUCH
ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL10-02
63 A3033A 4
PLUG
埋栓
PT1/4
64 Y3054H 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL08-99
65 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQW06-99
66 K5030B 1 CONNECTOR ｺﾈｸﾀ UY6
67 Y3020K 1 UNION ﾕﾆｵﾝ TSM6-01
68 S1053F 1
SILENCER
ｻｲﾚﾝｻ KM-11
69 Y3045G 6 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ TL4-M5M
70 Y3117A 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ TS6-01M
71 Y3020F 4 UNION ﾕﾆｵﾝ TL6-01M
72 Y3049E 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-M5
73 S2177A 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ TS6-02
74 Y3056B 1
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQH06-M6
75 H3118A 8
PLUG
ﾌﾟﾗｸﾞ P-M5
76 ABHPP8010 6 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ
77 Y3020L 4 UNION ﾕﾆｵﾝ UB4M
NP-153E PARTS LIST ver03
26 - 3
26.ｴｱｰ配管図
26.Pneumatic circuit diagram
26.ｴｱｰ配管図
26.Pneumatic circuit diagram
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
78 4 JOINT ｼﾞｮｲﾝﾄ TSH4-M3M
79 Y3045F 6 ELBOW ｴﾙﾎﾞ TL4-M3M
80 H3120F 2 PLUG ﾌﾟﾗｸﾞ UP4
81 S2153A 2 JOINT ｼﾞｮｲﾝﾄ TSH4-M5M
82 Y3045L 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ SL16-03
83 A3036A 2
PLUG
埋栓
PT3/8
84 Y3049A 4
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-M5
85 S2155A 1 JOINT ｼﾞｮｲﾝﾄ TS10-02
86 Y3055S 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL16-03S
87 Y30417 2 UNION ﾕﾆｵﾝ KQT16-00S
88 1 UNION ﾕﾆｵﾝ KQT16-03S
89 1 UNION ﾕﾆｵﾝ KQF06-03
90 Y3056E 1
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQH06-01S
91 Y3056C 1
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQH06-00
92 Y3055W 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL16-00
93 Y3050M 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-00
94 Y3071T 2 UNION ﾕﾆｵﾝ KQ2T08-06
95 Y3049T 4 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-01S
96 Y3061T 4 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS06-M5
97 Y3049H 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-M5
98 4 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-M5M
101 N2033T 1
NIPPLE
ﾆｯﾌﾟﾙ KQN06-99
102 Y3056E 8
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQH06-01S
103 8 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQH16-03S
NP-153E PARTS LIST ver03
26 - 4
26.ｴｱｰ配管図
26.Pneumatic circuit diagram
