28.1.PFU 残ﾃｰﾌﾟｶｯﾀ(DAUF)
28.1.PFU Waste tape(DAUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DBYH0010 3 STAND ｽﾀﾝﾄﾞ
2 DDUF0180 1 CATCH PAN 受け皿
3 DDUF0320 1 DUCT ﾀﾞｸﾄ
5 DDUF0330 1 COVER ｶﾊﾞｰ
6 DDUF0380 1 PLATE ﾌﾟﾚｰﾄ
7 DDUF0280 1 BASE ﾍﾞｰｽ
8 DDUF0290 1 FRAME ﾌﾚｰﾑ
9 DDUF0220 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
10 DDUF0200 1 PLATE ﾌﾟﾚｰﾄ
11 DDUF0300 1 COVER ｶﾊﾞｰ
12 DDUF0340 1 COVER ｶﾊﾞｰ
13 DDUF0240 1 COVER ｶﾊﾞｰ
14 DDUF0020 1 COVER ｶﾊﾞｰ
15 DDUF0190 2 GUIDE ｶﾞｲﾄﾞ
16 DBUF0140 6 COLLAR ｶﾗｰ
17 DBUF0150 3 GUIDE ｶﾞｲﾄﾞ
18 DBUF0180 10 COLLAR ｶﾗｰ
19 DDUF0210 2 STOPPER ｽﾄｯﾊﾟ
20 DDUF0100 1 PACKING, RUBBER ﾊﾟｯｷﾝ ｺﾞﾑ
21 DDUF0390 1 PLATE ﾌﾟﾚｰﾄ
22 DBVH0340 1 COVER, BLIND 蓋 盲
24 DBUF0230 5 GUIDE, HOLDER ｶﾞｲﾄﾞ 受け
25 DBVH0360 1 PIN, LOCATING ﾋﾟﾝ 位置決め
26 DBVH0370 1 PIN, LOCATING ﾋﾟﾝ 位置決め
27 CGUF0270 2 COLLAR ｶﾗｰ
28 CGUF0281 2 PIN ﾋﾟﾝ
29 CGUF0290 2 COLLAR ｶﾗｰ
30 CGUF0480 2 JAW 爪
31 CGUF0490 2 BLOCK ﾌﾞﾛｯｸ
32 WSD0014 40 CLAMPER ｸﾗﾝﾊﾟ
33 WSD0641 40 BOLT ﾎﾞﾙﾄ
34 WSD0652 40 SPRING ｽﾌﾟﾘﾝｸﾞ
35 KPA2240 2 COLLAR ｶﾗｰ
36 DDUF0010 5 CLAMPER ｸﾗﾝﾊﾟ
37 DBUF0260 4 BOLT, POSITIONING ﾎﾞﾙﾄ 位置決め
NP-153E PARTS LIST ver03
28 - 2
28.1.PFU 本体(DAUF)
28.1.PFU Body(DAUF)
28.1.PFU 残ﾃｰﾌﾟｶｯﾀ(DAUF)
28.1.PFU Waste tape(DAUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
38 DBUF0270 4 BOLT, POSITIONING ﾎﾞﾙﾄ 位置決め
39 DBUF0280 20 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ
40 DDUF0030 5 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え
41 H4435T 40
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1150ZZ
42 R5025T 40
ROLLER, NEEDLE
ﾛｰﾗ ﾆｰﾄﾞﾙ ﾟ5X10
44 H51373 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ UST4-30
45 K1089E 4
CAM FOLLOWER
ｶﾑﾌｫﾛｱ CF-SFU-10
46 Y3079T 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L08-02S
47 W1089A 6 WASHER ﾜｯｼｬ WSSB20-6-3
48 A1845DAUF0561 2 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え
49 A1845DAUF0571 2 BKT BKT
50 CGUF0730 2 BLOCK ﾌﾞﾛｯｸ
51 CGUF0740 1 BKT, SENSOR BKT ｾﾝｻ
52 CGUF0750 1 BKT, SENSOR BKT ｾﾝｻ
53 DDUF0270 1 COVER ｶﾊﾞｰ
54 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
56 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
57 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12L
58 H5280A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X20L
59 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L
60 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
61 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
62 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
63 H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X18L
64 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
65 H5303A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X25L
66 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L
67 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L
68 H5350A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X70L
69 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
70 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
71 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
72 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
73 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
74 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
NP-153E PARTS LIST ver03
28 - 3
28.1.PFU 本体(DAUF)
28.1.PFU Body(DAUF)
28.1.PFU 残ﾃｰﾌﾟｶｯﾀ(DAUF)
28.1.PFU Waste tape(DAUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
75 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
76 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
77 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
78 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H
79 W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H
80 K5170T
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M3X6L
81 K5209A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X8L
82 K51721
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M3X5L
83 .
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M6X8L
84 K5215A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X10L
85 K5257A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L
86 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7
87 N1086A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 3Type
88 N1076A NUT, HEX ﾅｯﾄ 六角 M3 3Type
89 H5170A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2.6X6L
90 H5281A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X25L
91 S31145 2 SW, PROXIMITY SW 近接 APM D3A1
92 DDUF0230 1 COVER ｶﾊﾞｰ
94 DDUF0090 1 BKT BKT
95 DDUF0350 2 BKT BKT
96 DDUF0360 2 BKT BKT
97 DDUF0370 2 SUPPORT COLUMN 支柱
98 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L
99 N1092A
NUT, HEX
ﾅｯﾄ 六角
M10 P=1.5
100 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
101 K5210A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X10L
102 N1093A
NUT, HEX
ﾅｯﾄ 六角
M10 P=1.5ﾋﾀﾞﾘ ･
103 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
104 K5208A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ MSX6L
