Maintenance Manual | 17 ¾ DANGER : Do not operate the system with the back cover open ed. The negligence of the safety instruction can lead to w ound/injury of operator . ¾ …
16 | KY-8030 2
3DSolderPasteInspectionSystem
Version 1.0
KOH YOUNG TECHNOLOGY INC.
¾ DANGER:Donotdisassemblethe safety sensor/safety sensor key when operating the
system.Thenegligenceofthesafetyinstructioncanleadtowound/injuryofoperator.
¾ DANGER:Donotoperatethesystemwiththebackcoveropened.Thenegligenceofthe
safetyinstructioncanleadtowound/injuryofoperator.
Safety Sensor
Safety Sensor Key
Maintenance Manual | 17
¾ DANGER:Donotoperatethesystemwiththebackcoveropened.Thenegligenceofthe
safetyinstructioncanleadtowound/injuryofoperator.
¾ WARNING:Turn the systemoff during part replacement or system calibration. When
thesystemhascompletelystopped,removethepowercablefromthepowersupplyand
thenfollowtherequiredstepsforreplacementorcalibration.
¾ WARNING:Make sure to keep hands and other objects out of the buffer conveyor on
eitherside.Failuretodosomayleadtopersonalinjuryorsystemerror.
¾ WARNING: No person other than an operator should be allowed into the system
operationarea.
¾ CAUTION:Donotattempttomanipulatethevarioussensorsattachedtotheconveyors
ontheleftandrightsidesofthesystembyyourself.Itmayleadtosystemerrororother
problems.
Rear Cover
18 | KY-8030 2
3DSolderPasteInspectionSystem
Version 1.0
KOH YOUNG TECHNOLOGY INC.
DuringMaintenance
¾ DANGER:Before proceedingwithmaintenance, remove thepowercableandplacean
ʺUnderInspectionʺtagonittopreventothersfromconnectingittoapowersupplyby
accident.
¾ WARNING: Before proceeding with maintenance, depressurize the air filter regulator
usingtheairreleasevalve.
¾ WARNING:Onlythosewithsufficienttrainingonthesystemcanperformmaintenance,
inspection, calibration, lubricationor cleaning activities.Always shut down thepower
andthecompressedairtothesystembyfollowingthespecifiedsteps,andthenproceed
withmaintenanceactivitiessafely.
¾ WARNING:WhenitbecomesinevitabletoperformajobwhilethesystemisON,make
suretoperforminspectionandverificationonthesysteminmanualmode
Under Maintenance
Under Maintenance
AIR-IN AIR-OUT
Air Release Valve
