Page SAMSUNG TECHWIN 98 SM451 E lectric Panel Ass’y (2/2) LC1D096BD LC1D096BD LC1D096B D LC1D096B D 1 2 3
Page
SAMSUNG TECHWIN
97
SM451
Electric Panel Ass’y (1/2)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J90781012A SM451 REAR ELECTRIC PANEL ASSY 1
1 J3501040A MAGNETIC CONTACTOR 1
2 J3603015A CIRCUIT PROTECTOR 1
3 J3603016A CIRCUIT PROTECTOR 1
4 J3601018A FUSE 3
5 J3601019A FUSE 2
6 J3716042A STOPPER 2
7 J3716044A TEMINAL BLOCK 68
8 J3716046A END PLATE 13
9 J3716047A CROSS CONNECTION 5
10 J3716067A FUSE TERMINAL BLOCK 5
11 J91741087A SAFETY CONTROL DC POWER BOARD 1
12 J7251007A BOARD COVER 1
13 J3105010A COOLING FAN 4
Page
SAMSUNG TECHWIN
98
SM451
Electric Panel Ass’y (2/2)
LC1D096BD
LC1D096BD
LC1D096BD
LC1D096BD
1
2
3
Page
SAMSUNG TECHWIN
99
SM451
Electric Panel Ass’y (2/2)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 J3153056A SERVO MOTOR DRIVER(750W) 1
2 J3153057A SERVO MOTOR DRIVER(1KW) 2
3 J3153055A SERVO MOTOR DRIVER(100W) 9
4 J90831423C AXIS SENSOR BD PW CABLE ASSY 1 J90831423B
5 J90831365A TRANSFORMER INPUT EXT CABLE ASSY 1
6 J90831345A NF1 MAIN SWITCH CABLE ASSY 1
7 J90831347A TRANS CP1-2 CABLE ASSY 1
8 J90831296E X MOTOR ENC CABLE ASSY 1
9 J90831339C Y1 MOTOR ENC CABLE ASSY 1
10 J90831332B REAR EMDOORFD CHG SW CABLE ASSY 1
11 AM03-003813A X MOTOR POWER CABLE ASSY 1 J90831337C / J90833696A
12 AM03-003814A Y1 MOTOR POWER CABLE ASSY 1 J90831338A / J90833697A
13 J90831363B REAR MONITOR POWER CABLE ASSY 1 J90831363A
14 J90833386A HEAD IF B/D PWR CABLE ASSY 1
15 J90833515B Y1-Y2 DRV COMMAND CABLE ASSY 1 J90831382C
16 J90833402C WD,X DRV CMD CABLE ASSY 1 J90833402A
17 J90831384C CONVEYOR BELT C0MMAND CABLE ASSY 1 J90831384B
18 J90833387A VME IO B/D PWR CABLE ASSY 1
19 J90831331C FRONT EMDOOR READY SW CABLE ASSY 1
20 J90831334B CONVEYOR SUB CONN CABLE ASSY 1
21 J90831060E F OVERRIDE KEY EXT CABLE ASSY 1 J90831060C
22 J90831130B CONV IF BD POWER CABLE ASSY 1
23 AM03-003815A Y2 MOTOR POWER CABLE ASSY 1 J90831448A / J90833698A
24 J90831451C WD MOTOR POWER CABLE ASSY 1 J90831451B
25 J90831362C FRONT MONITOR POWER CABLE ASSY 1 J90831362B
26 J90831449D Y2 MOTOR ENC CABLE ASSY 1 J90831449C
27 J90831452E WD MOTOR ENC CABLE ASSY 1
