Page SAMSUNG TECHWIN 103 SM451 E lectric Device Ass’y (1/4) NO. P ART NO. P ART NAME Q'TY Old No. Stock Apply Reference A-1 J9168101 5A SM451 ELECTRIC DEVIC E ASSY 1 1 J5201 1002A MINI KEYBOARD 1 2 J5301 1032A LCD M…
Page
SAMSUNG TECHWIN
102
SM451
Electric Device Ass’y (1/4)
\
AIR PRESSURE
SAFEGUARD
OVERRIDE
MAIN SWITCH
]
STOP
RESET
SELECT
FEEDER
CHANGE
ST
AR
T
READY
Y
X
[
^
Front Power Panel Ass'y
SAFEGUARD
OVERRIDE
MAIN SWITCH
MAIN SWITCH
`
_
Z
Page
SAMSUNG TECHWIN
103
SM451
Electric Device Ass’y (1/4)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J91681015A SM451 ELECTRIC DEVICE ASSY 1
1 J52011002A MINI KEYBOARD 1
2 J53011032A LCD MONITOR-15 1 J53011015A
3 J6309025A FAN GUARD 2
4 J7452038A MOUSE PAD-OPTICAL 1
5 J47131010A TOWER LAMP 1 J47131013A
6 J90601023B TEACHING BOX 1
7 J52021011A OPTICAL MOUSE 1 J52021006A
8 J34060005B LOAD SWITCH 1
9 J3409029A KEYLOCK SWITCH 1
Page
SAMSUNG TECHWIN
104
SM451
Electric Device Ass’y (2/4)
[CH1]
TRAY
NEXT
PREVIOUS
LAN
MCCB
GROUND
INTERFACE
[CH2]
FEEDER
Rear Power Panel Ass'y
2
3
1
4
[
CH1]
TRAY
NEXT
PREV
IOU
S
LAN
MCCB
GROUND
INTERF
ACE
[CH2]
FEEDER
ST
OP
RESET
SELECT
FEEDER
CHANGE
STAR
T
READY
XT
PREV
IOU
MC
TERF
ACE
F
F
9
6
5
7
8
