Page SAMSUNG TECHWIN 49 SM451 H ead Ass’y (3/5) NO. P ART NO. P ART NAME Q'TY Old No. Stock Apply Reference A-1 J9055138 5A HEAD_MODULE_1F_A SSY 1 1 J6601 1 134A BEARING 1 2 J71551370A Z-ST OPPER 1 3 J71551371A Z-CA…
Page
SAMSUNG TECHWIN
48
SM451
Head Ass’y (3/5)
35
33
1
2
8
9
40
41
34
32
50
25
39
24
37
42
19
20
11
43
44
28
23
21
22
16
15
13
18
10
26
30
31
3
4
49
49
5
12
27
29
14
38
6
48
45
46
7
17
36
47
Page
SAMSUNG TECHWIN
49
SM451
Head Ass’y (3/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J90551385A HEAD_MODULE_1F_ASSY 1
1 J66011134A BEARING 1
2 J71551370A Z-STOPPER 1
3 J71551371A Z-CAP 1
4 J71551372A Z-CAP SPACER 1
5 J71551373A Z-CAP NUT 1
6 J71551374A Z-CAP COVER 1
7 J71551375A NUT HOUSING LOWER 1
8 J71551376A Z-CUSHION 1
9 J71551377A Z-COMP SPRING 1
10 AM03-003953A ASSY,ETC,IMS-Z HOUSING 1 J71551359A / J71551359B
11 J66121040B COUPLING 1
12 J31081030A SERVO MOTOR 1
13 J71551389A NOZZLE HOLDER-P 1
14 J71551394A SCREEN-NZ-HD 1
15 J71551390B VACUUM HOUSING 1 J71551390A
16 J67191064A Y-PACKING 2
17 J90551386A SM451_COMMON_NOZZLE_HOLDER_ASSY 1
18 J7255021B SILICON TUBE 1
19 J71551391A AIR PIN 1
20 J67111151A FITTING 1
21 J71551392A SENSOR DOG-F 1
22 J71551393A SPACER NZ HD-1 1
23 J71551379A Z-BEARING NUT 1
24 J67111151A FITTING 1
25 J7458002A FILTER ELEMENT 1
소모품(교환: 6개월)
26 J67111068A BARB FITTING 1
Page
SAMSUNG TECHWIN
50
SM451
Head Ass’y (3/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
27 J71551382A SUPPORT BACK 4
28 J71551360B BACK PLATE 1 J71551360A
29 J71551383A HOLDER STOP 1
30 J71551384A SENSOR PLATE 1
31 J3212027A SENSOR 3
32 J71551385A R-SENSOR DOG 1
33 J71551386A Z-CONN BKT 1
34 J71551387A CABLE CLAMP-U 1
35 J71551388A Z-TUBE CLAMP 1
36 J70551524A SPRING BKT 1
37 J70551522A PIN Z-1 1
38 J70551525A Z-SPRING 1
39 J71551381A FILTER CAP 1
40 J71551380A U PACKING 1
41 J72551067A FILTER CAP COVER 1
42 J70551526A MOTOR CABLE BKT 1
43 J70551528A OUTTER COLLAR 1
44 J66011135A ANGULAR_BEARING 1
45 J90551357A Z-BALL SPLINE ASSY 1
46 J90551388A_AS SM451 BALL SPLINE ASSY 1 J90551388A
47 J67111169A FITTING_ELBOW 1
48 J67111068A BARB_FITTING 1
49 J1300512 BALL BEARING 2
50 J60497987 WAVE_WASHER 1
